FA40I Ingersoll Rand встроенный фильтр фильтры серии F спрессованного воздуха компрессора инлииновый FA75I


Поделиться:


Цена:*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-15-2025 0.80 $* 0.6 $*
Aug-15-2025 0.35 $* 0.73 $*
Jul-15-2025 0.13 $* 0.15 $*
Jun-15-2025 0.96 $* 0.39 $*
May-15-2025 0.64 $* 0.94 $*
Apr-15-2025 0.42 $* 0.75 $*
Mar-15-2025 0.20 $* 0.97 $*
Feb-15-2025 0.61 $* 0.0 $*
Jan-15-2025 0.4 $* 0.67 $*

Характеристики




FA40I

Grade:A G H D

Ingersoll Rand



plz contact me for more information and exact price





Air Compressor Filters



Air Compressor Dryers

Refrigerated Dryers, Desiccant Dryers and filters; Air quality can have a significant impact on compressed air systems. Properly treated compressed air, and the right air dryer, will improve productivity, system efficiency, and product or process quality. Choosing the appropriate air dryer and compressed air filter is very important. By choosing an Ingersoll Rand air dryer or compressed air filter, you are buying high quality treatment products that will enhance your entire air compressor system. An air dryer is an integral piece in your air treatment system, making Ingersoll Rand's wide knowledge and expertise in this field a key aspect to the success of your compressed air system. Ingersoll Rand has the widest selection of air treatment products and application knowledge to protect your investment and compressed air system.



AIR TREATMENT

filters

Non-Cycling Refrigerated Dryers

Heatless Desiccant Dryers

Heated Desiccant Dryers

Cycling Refrigerated Dryers

HOC Desiccant Dryers

Non-Cycling Refrigerated Dryers 0.2-8 m3/min, 7-212 cfm

Capacity Range: 7-212 cfm (0.2-8 m3/min)

Pressure Dew Point: 38°F to 50°F (3°C to 10°C)

ISO Class 4 to 6

Cooling Method: Air-cooled

Voltage: 115/1/60, 230/1/50

Maximum Pressure: 203 psig (14 barg)

Maximum Ambient (air cooled): 122°F (50°C)

Maximum Inlet Temperature: 140°F (60°C)

Refrigerant: R-134A



FEATURES:

  • Reduced Energy Use: Efficient heat exchangers, a built-in stainless steel demister that removes all moisture and a fully adjustable programmable electronic drain valve reduce energy use and minimize air loss
  • Built-in Reliability: Corrosion-resistant heat exchangers, an enhanced control-system and high-efficiency moisture-separation ensure a steady long-term supply of dry air
  • Smart Control: Easy to use, advanced microprocessor control that lets you easily adjust and manage system parameters
  • Equipment Protection: Built-in coalescing filter stops contamination by separating water and oil from the compressed air
  • Consistent Clean, Dry Air: Variable-speed fans reduce power consumption when units operate at less than maximum cooling capacity, while ensuring a consistent dew point

F-Series Filters

F-Series advanced compressed air filters reduce contamination in your air stream to help protect critical processes and valuable equipment. Rigorously tested and engineered with superior components, F-Series filters will provide years of reliable performance and consistently high quality air.

Features:

  • Accurate Information: Patented dual indicator shows differential pressure drop and operating efficiency
  • Rugged Design: All-aluminum, precision die cast body suitable for 176 F / 80 C and 250 psig / 17.2 bar MAWP applications
  • Reliable Operation: Filter element with stainless steel mesh withstands high pressure and minimizes flow restriction
  • Easy Maintenance: Ergonomic bowl design with no-touch filter simplifies element replacement
  • Lone Element Life: Proprietary media coating technology protects against corrosion and increases element life




A

Patented dual indicator shows differential pressure drop and economical operating efficiency

B

Patented smooth bore flow insert directs air into the filter element, minimizing turbulence and pressure losses

C

All-aluminum, precision die cast body suitable for 80°C (176°F) and 17 bar g (250 psig)MAWP applications

D

Proprietary coating applied to the inside and outside surfaces provides corrosion protection in harsh industrial environments

E

Filter element with stainless steel mesh withstands high differential pressure while minimizing flow restriction through the element

F

Ergonomic bowl design with no-touch filter element simples element replacement

G

Time strip label indicates when it's time to change the element (A Grade only)

H

Industrial-grade brass float drain discharges accumulated condensate and oil more reliably than lesser quality plastic drains (no-loss and manual drains also available)

I

Deep-pleated filter media reduces air flow velocity to maximize filtration efficiency and minimize pressure losses

J

High-efficiency drainage layer improves liquid drainage properties and enhances chemical compatibility

K

Simple visual alignment of the filter head and bowl ensures accurate assembly of components and helps to improve safety



Specification

Filter model number Pipe sizeFlow rates
100psig/7 bar g
ModelGradeinm3/min
FA30IA, G, H, D3/8”0.4817
FA40IA, G, H, D1/2”0.6222
FA75IA, G, H, D3/4”1.2745
FA110IA, G, H, D3/4”1.8465
FA150IA, G, H, D1”2.4988
FA190IA, G, H, D1”3.12110
FA230IA, G, H, D1”3.82135
FA400IA, G, H, D1.5”6.66235
FA490IA, G, H, D1.5”8.21290
FA600IA, G, H, D2”9.91350
FA800IA, G, H, D2”13.3470
FA1000IA, G, H, D2”17600
FA1200IA, G, H, D3”20.1710
FA1560IA, G, H, D3”26.1920
FA1830IA, G, H, D3”30.61080
FA2300IA, G, H, D3”38.21350
FA2700IA, G, H, D3”45.31600
