Строгальные станки BK5018 cnc вертикальный строгальный
- Категория: Рубанок и долбежные станки >>>
- Поставщик: Taian,Haishu,Machinery,Co.,Ltd.,[Shandong,China]Taian
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 707593.34 $* | 742973.43 $* |
| Aug-19-2025 | 701647.83 $* | 736729.43 $* |
| Jul-19-2025 | 588670.18 $* | 618104.43 $* |
| Jun-19-2025 | 689755.85 $* | 724243.83 $* |
| May-19-2025 | 600562.1 $* | 630590.3 $* |
| Apr-19-2025 | 677862.52 $* | 711755.11 $* |
| Mar-19-2025 | 671916.8 $* | 705512.80 $* |
| Feb-19-2025 | 665970.22 $* | 699269.44 $* |
| Jan-19-2025 | 660024.97 $* | 693025.45 $* |
Характеристики
Slotting Machines BK5018 cnc vertical planer
cnc vertical planer BK5018 CNC Slotting Machine
Item | Unit | Specification |
Ram maximum slotting length | mm | 180 |
Ram stroke adjustment | mm | 80 |
Ram movenent times | N/min | 46/60/90 |
Work table size | mm | 600X320 |
Trael of table(X,Y) | mm | 460X320 |
The knife head suppoting hole axis to column forarm distance | mm | 400 |
The knife head supporting hole end to Table working distance | mm | 480 |
X to the motor torque | N.M | 6 |
Y to the motor torque | N.M | 6 |
Fast moving | X(m/min) Y(m/min) | 5 5 |
Ball screw X |
| FFZD3205-3/P4 |
Ball screw Y |
| FFZD3205-3/P4 |
The main motor power | kw | 1.5/2/2.2 |
Machine weight | kg | 1500 |
