Порошковая Вибрирующая флюидизированная кровать сушилка в флюидизированной плате промышленная высокого

Описание и отзывы

Трекер стоимости

Характеристики

Fluidized bed dryer drying machine



Brief Introduction of Fluid Bed Dryer Drying Machine:



Dryer Name	vibrating fluidized bed dryer drying machine in fluid bed drying machine
Dryer Structure	feeder, conveyor-belt, induced drafft fan, exhaust fan, heat exchanger, vibrating motor, vibrating separating spring, air tube, etc.
Dryer Color	common is green, blue, silver, grey, white.
Designed Electric Power	Voltage: 110V, 220V, 240V, 380V, etc. as suctomers' requirements. Electric Hertz: 50Hz, 60Hz Electric Type: single phase, two-phase(qusrter-phase), three phase. The specific design of electric power is acording to the customers' requirements because it is defferent betweet countries, like China(mainland), Chile, Egypt, Iraq and Switzerland are all 220V.
Heating Temperature	adjustable through the electric control cabinet.
Raw Material of Dryer	(1) stainless steel (2) carbon steel (3) other steel materials suitable for the dryer drying machine.



Payment: (1). The price of dryer drying machine is according to the specific different technical requirements, overall size and some other details. (2). What we offer common is FOB Shanghai price. If indeed, we can also offer the CIF Shanghai and even EXW price.



Packaging & Shipping: (1). We common choose the custom-made wooden case and transparent coating to packaging the dryer drying machine, or directly packaged into the shipping container. (2). The shipping date is according to the sales contract.





Working Principle of Fluid Bed Dryer Drying Machine:

ZLG Vibrating fluid - bed drier is widely used in chemical industry, light industry, medicine, food, plastic, edible oil, slag, salt, sugar and other industries of the powder of dry granular materials, cooling, humidifying, etc.

Material from the feed port into the machine, under the effect of vibration power, the material along the horizontal throwing straight forward movement, hot air upwards through the fluidized bed with wet material after heat, wet air outlet after cyclone dust removal by the discharge, dry material is being exhausted from port discharge.













Features Of Fluidized Bed Dryer Drying Machine:

1. Raw material is heated evenly, heat exchange is fully, and large intensity of drying use vibration motor as vibration source. It is smooth in running and convenient in maintenance. The noise is low and the life is long.

2. The state of fluidization is uniform and no dead gaps and broken phenomenon. Therefore the dried, cool can be got. It is good in adjustment and width in field of application. The thickness of raw material and the speed of raw material to be moved inside the machine and the change of vibration breadth can be realized through steeples.

3. Fluidized bed is small to damage the surface of raw material, so it can be used for raw materials that are easy broken. If the granule is not normal, the effect of process can not be effected. Because of adapting the structure of fully seat, it is effective to prevent from the cross pollution of raw materials and the working environment is clean. Basically the drying time is on average, the staying time is short, and the thickness of fluidized bed is also very short, 2-5cm.





Application Field:

Inorganic: sulfate, fine bleaching pink, sodium metasilicate, silica sand, boric acid sodium, activated carbon, sulfate, sodium chlorate, borax, boric acid, XiuHuaJia, brominated sodium

Organic matter: benzene 2 phenol, oxalic acid, hydroquinone, fumarate, cologne acid, catechol, between the benzene 2 phenol, coke powder, tartaric acid, dichloroisocyanurate, G salt, R salt.

Food and feed additive: soybean protein isolated, glutamic acid, caramel pigment, yeast powder, citric acid, citric acid sodium, glucose, lactose, sugar.

Pesticide: willy aldehyde in spirit of rotor granules.

Chemical agents: sodium percarbonate

The high polymer: PE, PAM
