We manufacture cost-effective & qualified Erowa fixture equivalent

EROWA fixture; rapid positioning fixture; CNC fixture; EDM fixture; electrode chuck; 3R fixture; manual chuck; pneumatic chuck; reducer; ; Stainless steel chuck; aluminum chuck; ITS chuck; heavy chuck; gravity chuck.

ITS Spindle Chuck Pneumatic

ER-007521: Rapid-action chuck automatic

Version: Standard type. Clamping power up to 2500 N.

Connections: On back.

Application: EDM sinking machines with automatic electrode change, machine tools with automatic loading, production lines.

Technical data ITS Chuck:

Repeatability: 0.002 mm (0.00008“)
Indexing: 4x90° divisible
Chuck clamping power: 2‘500 N, generated by springs.
Chuck opens with: 6 bar (88 psi) compressed air
Recommended workpiece size: 140x140x140xmm (5.5x5.5x5.5“)

ITS Quill Chuck Mechanic

ER-038826 QuickChuck 100 P / R

Version: On a ø 110 mm base plate with a rotatable flushing connection.

Attachment: With 4 x M6 bolts.

Application: On EDM centers with quill rotation.

Note: Clamping power: up to 10000 N.

ITS Table Chuck Pneumatic

ER-007604 Manual rapid-action chuck NSF

Version: NSF = increased clamping power up to 7000 N.

Connections: Pneumatic valves on side, flushing on back.

Application: Electrode fabrication general.NoteTo clamp pallets of ø 115 / ø 148, ø 72 and electrode holder 50. Pallets with P centering system are excluded.

ITS Table Chuck Pneumatic Stainless

ER-007536 Rapid-action chuck automatic with sealing cap

Version: Stainless. NSF = increased clamping power up to 7000 N.

Connections: On the side.

ApplicationWith cooling/flushing water conducive to corrosion.

ITS Table Chuck Mechanic

ER-007697 Screw chuck 50 D

Version: Only 20 mm overall height. For holders of
system size 50.

Connections: Central flushing possible.

Application: Small lathes, on tapers, flanges, jigs and fixtures.

ITS Table Chuck Mechanic Stainless

ER-034387 Quick Chuck 50

Version: System size 50, manual, corrosion‑resistant.

Attachment: 4 x M8 from the rear or 4 x M6 stud bolts with nuts.

Application: On EDM/WEDM centers for light milling and grinding work. Max. revolutions on rotating axes 200min¹

Note: Clamping power up to 4000 N.

Kinds of chuck

Electrode holder

brass,stainless steel,aluminum

Accessoires

Meet your various requirements

Carefully packaged,well protected
