1mw/5mw/10mw/20mw/30mw 650nm VFL волоконный источник света ручка и Визуальный

Output power

10mw

Size

100*30*18（mm）

Connector type

FC/2.5mm universal connector For 1.25mm connectors, FC (Male)-LC (Female) convertor can be optional on customer requests

Operating model

Both CW and Pulse available

Package

1pc per box

Introduction

The KW315N Economical VFL is an efficient and low cost basic fiber test tool, it provides a visible way to find fiber faults and
identify fibers in an optical network during and after installation.

Function

◇ Finding the breakpoint, poor connections, bending or cracking in fiber optic cables.
◇ Finding the faults of OTDR dead zone
◇ End-to-end visual fiber identification

 Features

◇ Constant & stable output power
◇ Special laser driver circuit design, to make sure the laser output power remains a constant power level as long as in an
available battery voltage.
◇ Low battery warning, reminds users to change the battery timely.
◇ Long battery life(up to 40 hours with AAA batteries)
◇ Operates either in CW or Pulsed
◇ Pocket size and light weight, easy to use
