Nanjing Jinhui Heavy Duty Warehouse Metal Push Back Pallet Racking/ Pallet Racking System
Heavy duty storage rack usually consist of upright frame, beam, pallet support bar and other standard components. H-bracing and D-bracing connect with upright by nylon self-lock bolts,can effectively prevent racking from losing balance cause by the release of the bolts; Drum-shaped holes are punched on the upright, so beam can be adjusted by 75 mm .
Standard pallet racking is by far the most versatile of any racking as it is available with many configurations, a wide range of accessories and requires no specialized handling equipment. Pallet racking is easily utilized with just standard fork- and hand-trucks. Pallet racking is an ideal starting point for all your warehouse and storage needs.
Adjustable pallet racking systems come in many different styles, but it is important to get the basics right. For safe and efficient operation, pallet racking systems must be designed to fit and function with both the handling equipment and the load. Pallet racking systems may have to work with counterbalance trucks, reach trucks, narrow aisle trucks or automated handling equipment.
Specification of beam table:
Length
1500
1800
2000
2300
2500
2700
3000
3300
Beam Specification
Load/kg
80×50
3000
2300
1800
1500
1200
1000
800
700
100×50
4000
4000
3000
2400
2000
1750
1400
1100
120×50
4000
4000
4000
3500
3000
2500
2000
1800
140×50
4000
4000
4000
4000
4000
3800
3000
2500
Advantage:
1) Material quality : High quality Cold-rolled/Q235 Steel;
2) Ideal for large quantity and bulk operation, and pallet racks; 3) Surface treatment: Epoxy powder coated and color optional;
4) Easy to install and dismantle;
5) Warranty: 3-5 years guarantee from the delivery date 6) High quality and good appearance;
7) Fully utilizes vertical space, Suitable for storing pallets;
8) Compatible with most types of handling equipment, To achieve a variety of size and weight of the tray quick access;
9) each layer carrying up to 500-3000kg;
10) The reliable and efficient service before and after deal.
