This kind of pressure transmitter can be directly joined with computer joint clip, control instrument ,aptitude instrument or PLC etc. conveniently. The series' product is applied extensively in the professions, such as the industry process control, petroleum, chemical engineering and metallurgy etc. Carry the distance delivers and can adopt electric current exportation method.
Pressure range
Pressure Type
gauge pressure absolute pressure sealed pressure
Pressure range
1-600Bar (optional)
Technical Index
Power supply
24VDC 12VDC 12-36VDC
Signal output
4-20mA 0-20mA 1-5V 0-5V
Signal line specification
2wire 2wire 3wire 3wire
Zero Drift
±0.03%FS/°C
Accuracy
±0.1%FS ±0.3%FS ±0.5%FS
Thermal Sensitivity Shift
±0.03%FS/°C
Longterm Stability (1 Year)
<=0.21%FS
Frequency Response (-3dB)
5kHz~650kHz
Compensated Temperature
-10~70℃
Working Temperature
-40~85℃
Storage Temperature
-40~125℃
Overload pressure
200%FS
Protection Classification
IP65
Body materials
316 stainless steel (standard)
Transmission distance
<= 100m (No electromagnetic interference)
Pressure connection
G1/4, G1/2, 1/2NPT, 1/4NPT, M12*1.5, M20*1.5 etc. (optional)
Measure media
Gas, water, oil or other media can be compated with stainless
Accuracy
±0.3%FS ±0.5%FS
Terminal Block Specifications
Hirschmann connector, aviation conncetor, direct lead
