Генератор сжиженного углеводородного газа 8 кВт 10 кВА с звукоизоляционным

Genset Model

KK8REG-FB

Outout Power

Rated power (LPG)

8KW

Rated power (NG)

7KW

Rated voltage (V)

230

Rated current (LPG)

34.8

Rated current (NG)

30.4

Phase number

Single phase

Rated speed (RPM)

3000

power factor

1.0

Frequency (Hz)

50

Engine

Engine warranty (year)

1

Engine item

2V78FD

Displacement (CC)

678

Compression ratio

8.5:1

ignition system

Electronic

Electrical startup

yes

Start motor specification

12V/0.8KW

Fuel type

LPG/NG

Bore*stroke (mm*mm)

V2-78*72

Aspiration

Natural inspiration

Oil capacity (L)

1.4

Rotary oil filter

yes

cylinder block

Aluminium alloy

Cylinder liner

cast iron

Charging mode

12V/3A charging coil

Recommended battery cold start current (CCA)

18Ah to 45Ah

Cooling system

Forced air cooling

High temperature shutdown

no

Low oil pressure shutdown

yes

AC Alternator

Alternator type

Synchronization generator, rotating magnetic field

Voltage regulation system

AVR automatic voltage regulation

Excitation type

Carbon brush

The number of poles

Two

Total harmonic distortion @ full load

Less than or equal to 5%

Insulation level

F

Stator winding material

copper

Rotor winding material

copper

Laminated material (cold or hot rolled)

cold rolling

Connection mode

Direct coupling (flanged connection)

Motor bearing

6306RS

Voltage stability

type

electronic

Sensing

single

Adjustable pressure

 ± 5%
