Луженая Медь силиконовые куртка провод экранированный кабель витая

Описание и отзывы

Трекер стоимости

Характеристики



1) Product: FEP cable
2) Style No.: AFFB
3) Size: 36AWG~10AWG
4) Rated Voltage: 600V
5) Rated Temperature:-60°C~+200°C
6) Conductor: tinned plated copper wire
7) Insulation: silicone rubber insulation

8) Color: red / yellow / blue / white / black / yellow green / brown / orange / purple / green / etc



Product features
*high temperature and low temperature performance

*excellent electrical insulation properties

*excellent chemical stability

*high voltage resistance

*aging resistance

*long service life

*soft and easy to install



Applications
*heating source for lighting
* electric machinery

* air conditioning

* oven
* drying path

* auto ignition

* household appliance



Section Area  mm2	Conductor construction NO.×mm	Insulation thickness mm	Number of cores	m/coil
0.2	7×0.20	0.4	below         37 cores	200
0.3	16×0.15	0.5		200
0.5	28×0.15	0.6		200
0.75	24×0.20	0.6		100
1	32×0.20	0.6		100
1.5	48×0.20	0.6		100
2.5	49×0.25	0.7		100
4	56×0.30	0.7	2~12	100
6	84×0.30	0.7	2~10	100
10	84×0.40	1	2~5	100
16	126×0.40	1.2		100
25	196×0.40	1.3		100
35	494×0.30	1.4		100
50	396×0.40	1.6		100
70	511×0.40	1.6		100
95	760×0.40	1.8		100
120	608×0.50	2		100
150	756×0.50	2.2		100
185	925×0.50	2.4		100
240	1221×0.50	2.6		100
