Плавающая головка фонтана с широким зонтичным

Цена:2 000,00 $*

Количество:

Product Description

Floating fountain head with wide umbrella nozzle

Specification		YTL2-50A		YTL2-50S		YTL2-50B		YTL2-65S
Specification		Top axis	Lower axis	Top axis	Lower axis	Top axis	Lower axis	Top axis	Lower axis
1	Material	aluminium alloy		stainless steel		aluminium alloy		stainless steel
2	Mesurement, highth*revolution diameter (cm)	55*50 cm		55*50 cm		60*60 cm		65*60 cm
3	Net weight (KG)	31Kg		35Kg		42Kg		58Kg
4	Reduction ratio	1:10	1:10	1:10	1:10	1:10	1:10	1:10	1:10
5	Cable max transmission distance (M)	500m		500m		300m		300m
6	Stepper motor the number of phases	2	2	2	2	2	2	2	2
7	Stepper motor voltage (AC)	80v	80v	80v	80v	80v	220v	220v	220v
8	Stepper motor power (W)	300w	350w	300w	350w	350w	700w	700w	700w
9	Stepper motor max holding torque (N/M)	6 N/M	8 N/M	6 N/M	8 N/M	8 N/M	14 N/M	14 N/M	14 N/M
10	Sensor input voltage	24v	24v	24v	24v	24v	24v	24v	24v
11	Highest head (M)	18m		18m		25m		35m
12	Highest rotationl speed (r/min)	75 r/min	45 r/min	75 r/min	40 r/min	90 r/min	60 r/min	120 r/min	60 r/min
13	180° shuttled back & forth (times per min)	42	30	42	30	42	40	60	40
14	90° shuttled back & forth (times per min)	70	50	70	50	60	60	90	60
15	45° shuttled back & forth (times per min)	135	60	135	60	115	80	160	80
16	5° shuttled back & forth (times per min)	1200	/	1200	/	1000	/	1200	/
17	Sensor positioning accuracy	The maximum deviation is 5mm (less than 0.1 degrees) by laser test at 30 meters distance
18	Stepper motor waterproof electric cable	JHS 4*2.5		JHS 3*2.5		JHS 4*2.5		JHS 3*2.5
19	Sensor anti-intereference electric cable	JHSP 3*1		JHSP 3*1		JHSP 3*1		JHSP 3*1
