Фланцевая роликовая
- Категория: Metal Forging Machinery >>>
- Поставщик: Dongguang,Huawei,Hydraulic,Pipe,Fitting,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 45220.77 $* | 47481.73 $* |
| Aug-20-2025 | 44840.98 $* | 47082.54 $* |
| Jul-20-2025 | 37620.91 $* | 39501.47 $* |
| Jun-20-2025 | 44080.40 $* | 46284.1 $* |
| May-20-2025 | 38380.40 $* | 40299.54 $* |
| Apr-20-2025 | 43320.71 $* | 45486.52 $* |
| Mar-20-2025 | 42940.91 $* | 45087.95 $* |
| Feb-20-2025 | 42560.67 $* | 44688.42 $* |
| Jan-20-2025 | 42180.30 $* | 44289.62 $* |
Характеристики
Product Description
| TYPE | forging weight(Max) | ID&OD range | Max height of ring | Motor TYPE | Guide pin | Machine Dimension (m) | Machine Weight(ton) |
| QF600A | 30KG | ID>160mm OD<800mm | 80 mm | 30KW-6grade | 4 guide pin | 2.5*2.3*2.2 | 2t |
| QF600B | 50KG | 100 mm | 45KW-6grade | 4 guide pin | 2.5*2.3*2.2 | 4t | |
| QF800A | 80 KG | ID>200mm OD<1000mm | 150 mm | 55 KW-6grade | 6 guide pin | 3.5*2.8*2.5 | 4.5t |
| QF800B | 150 KG | 200 mm | 75 KW-6grade | 6 guide pin | 3.5*2.8*2.5 | 5t | |
| QF1000A | 200 KG | ID>300mm OD<1200mm | 200 mm | 75 KW-6grade | 6 guide pin | 4.5*3*3 | 6.5t |
| QF1000B | 300 KG | 230 mm | 90 KW-6grade | 6 guide pin | 4.5*3*3 | 8t | |
| QF1200A | 300 KG | ID>300mm OD<1500mm | 260 mm | 90 KW-6grade | 6 guide pin | 5*3.5*3.3 | 9t |
| QF1200B | 500 KG | 110 KW -6grade | 6 guide pin | 5*3.5*3.3 | 11t | ||
| QF1500A | 500 KG | ID>300mm OD<2000mm | 300 mm | 135 KW -6grade | 6 guide pin | 7.5*4*4 | 13t |
| QF1500B | 1000 KG | 160 KW -6grade | 6 guide pin | 7.5*4*4 | 23t | ||
| QF1800 | 1000 KG | ID>300mm OD<2000mm | 300 mm | 160 KW -6grade | 6 guide pin | 12*5*5 | 28t |
| QF2000 | 1500 KG | ID>400mm OD<2500mm | 450 mm | 90 KW -6grade2sets | 8guide pin | 15*6*5 | 45t |
| QF3000 | 2000 KG | ID>500mm OD<3000mm | 650mm | 160 KW -6grade2sets | 8guide pin | 18*7*6.5 | 60t |
Packaging & Shipping
Packaging : plastic film or wooden box
delivery time :20-30days
