Flow Switches
FL-15 охладитель водонагреватель автоматический переключатель потока

FL-15 охладитель водонагреватель автоматический переключатель потока

Категория: Flow Switches >>>
Поставщик: Ningbo,Sanhe,Refrigeration,Co.,Ltd.

Цена:8,00 $ - 10,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	10.82 $*	11.78 $*
Aug-15-2025	9.66 $*	9.59 $*
Jul-15-2025	8.32 $*	8.84 $*
Jun-15-2025	9.83 $*	9.93 $*
May-15-2025	8.90 $*	8.73 $*
Apr-15-2025	9.30 $*	9.39 $*
Mar-15-2025	9.77 $*	9.38 $*
Feb-15-2025	9.90 $*	9.57 $*
Jan-15-2025	9.20 $*	9.58 $*

Характеристики

FL-15 chiller water heater automatic paddle water flow switch

Product Description

FL-15 (2)

Model	Connection Size (in)
FL-15	1/2"
FL-20	3/4"
FL-25	1"

Product Introduction:

FL Series flow switch is used to sense the flow rate of liquid in the pipe line, when the flow rate .reaches the setting point, it turns off (or turn on) to protect the torrential flow

The setting point could be adjusted according to different request of flow rate

Ambient temperature range: 0°C ~ 60°C

Liquid temperature, range: 5°C ~ 100°C

Max working pressure: 1.0Mpa

Electrical Function
Rated Voltage(V) Rated Amps(A)		Power CosΦ	125V AC	250V AC
Non-Inductive current		1	15	15
Induction current	Full load	0.75	3.5	2.5
Induction current	Instantaneous	0.45	21	15

Flow rate
Line Pipe Size(in)	Required to actuate switch(m3/h)
	Min. Adjustment		Max. Adjustment
	Flow Decreasing	Flow Increasing	Flow Decreasing	Flow Increasing
1"	18	21	45	50
1-1/2"	30	35	105	105
2"	50	58	150	155
2-1/2"	75	86	187	200
3"	100	115	225	260
