Китай грузовик с резервуаром для воды 8X4 Dongfeng на 30000 литров распылитель

Vehicle parameters

Vehicle Model

EHY5311GSSD

Vehicle Brand

HUAYI

Overall dimensions

11980X2500X3690mm

Curb weight

14205kg

Tank dimensions

8550X2300X1500mm

Tank volume

30000L

Chassis parameters

Chassis model

DFL1311A4

Chassis brand

DONGFENG

Overall dimensions

11475x2500x3030mm

Wheel base

1850+4600+1350mm

Front/rear wheel track

1940/1940/1860/1860mm

Front/rear suspension

1460/2135mm

Approach/departure angle

28/13°

Maximum speed

90km/h

Chassis Manufacturer

Dongfeng Motor Company

Cab

Configuration

D310 standard flat roof a row and a half deluxe cab(with sleeping berth),cab,air conditioner,electric glass,hydraulic mechanical flip, channel type instrument panel,central lock,allowable 3 passengers

Color

white,other color is optional

Engine

Model

C260 33

Emission

Euro 3

Type

6 cylinders,in-line,4-stroke,water-cooled,turbo inter-cooling,diesel engine

Rated power

260hp,rated power speed 2200rpm

Displacement

8300ml

Max.torque

1090N·m

Bore x stroke

114x135mm

Manufacturer

Dongfeng Cummins Engine Co., Ltd.

Tire

Size

11.00R20,steel wire tire

Number

12+1 nos

Brake

Double loop air brake system, exhaust brake

Clutch

Push type diaphragm spring clutch,Φ430

Frame

(300X80X[8+4])mm

Fuel tank

350L iron

Front axle

5.0 tons

Rear axle

10.0 tons,with ABS,main reduction ratio 4.44

Drive form

8X4

Rated voltage

24V,DC

Transmissions

Gearbox 9JS119T-B, 9 speed forward 1 reverse.

Steering device

Power assisted steering

Steering wheel

Left hand drive

Selective configuration

If there is a slight change in the chassis parameters above,please take the actual product as the standard
