AH2-Y задержки Регулируемый промышленный электронный таймер

AH2-Y задержки Регулируемый промышленный электронный таймер

Категория: Timers >>>
Поставщик: Shanghai,Shinuo,Electric,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.26 $*	0.48 $*
Aug-17-2025	0.16 $*	0.54 $*
Jul-17-2025	0.8 $*	0.28 $*
Jun-17-2025	0.3 $*	0.87 $*
May-17-2025	0.64 $*	0.70 $*
Apr-17-2025	0.57 $*	0.14 $*
Mar-17-2025	0.97 $*	0.59 $*
Feb-17-2025	0.53 $*	0.90 $*
Jan-17-2025	0.48 $*	0.4 $*

Характеристики

Product Description

Description:
- Using CMOS IC lower power consumption high reliability and stability
- 15 different time ranges from 0.1 sec to 24 hrs available (Each time range the product is individually customized)
- Power Supply
Non universal voltage: AC(V) 12 ,24, 110, 220 ,240 50/60Hz , DC(V) 12, 24
- Output Contacts rated 5A at 120/240 VAC and 30 VDC, resistive load.
- Front panel mounted with a P3G-08/US-08 Socket ).
- On-Delay version
- One delayed contact (SPDT Relay) + One instantaneous contact (SPDT Relay) Output
- Large and easy to read dial shows decimal points
- Two Leds provide status indication for ON-OFF operations

Technical Data :

Dimensions	88H×58W×68D
Mounting & Socket	Flush(-Y) US-08 P3G-08
Full timing range	SEC:1,3,6,12,30,60 MIN:3,6,12,30,60 HR:3,6,12,24
Rated voltage	DC(V):12 24 AC(V):12 24 110 220 240 50/60Hz
Indicator operating	ON-UP Two indicator Lamp
Contact O/P	Time limit 1C Instantenous 1C 5A Resistive load.
Life	Mechanical 5×106times Electrical 1×105times
Accuracy	Repeat error ±1%max Setting error ±10%max Voltage error ±1%max Temp.error ±2%max
Reset time	0.1sec max
Consrmed power	3VA
Ambient temperature	-10℃~+55℃
Ambient humidity	48~85%RH
Weight	220g

Connection Example:

Scale Drawings:

Company Information

Certifications

FAQ

1. Q: Do you have a catalogue? Can you send me the catalogue to have a check of all your products?
A: Yes , We have product catalogue.Please contact us on line or send an Email to sending the catalogue.

2. Q: I need your price list of all your products, do you have a price list ?
A: We do not have a price list of all of our products. Because we have so many items,and it’s impossible to mark all of their price on a list.And the price are always changing because of the producing cost.If you want to check any price of our products, please feel free to contact us.We will send offer to you soon!

3. Q: I can’t find the product on your catalogue, can you make this product for me?
A: Our catalogue shows most of our products,but not all.So just let us know what product do you need

4. Q: Can you provide samples ? Are the samples free ?
A: Yes,we can provide samples.Normally,we provide 1-3pcs free samples for test or quality checking.
But you have to pay for the shipping cos.If you need many items, or need more qty for each item,
we will charge for the samples.

5. Q: What kind of payment do you accept ? Can I pay RMB ?
A: We accept T/T(Wire transfer),Western Union and Paypal. Please be sure that we can receive the
same amount of the Invoice. And you can pay money In RMB. No problem.

6. Q : What about your delivery time?
A: We have a lot of products in stock.We can send the stock products in 3 work days.
If without stock,or stock is not enough, we will check the delivery time with you.

7. Q : How to ship my order ? Is it safe?
A: For small package, we will send it by Express, tsuch as DHL,FedEx,,UPS,TNT,EMS.That’s a
Door to Door service.
For big packages, we will send them by Air or By sea.We will use good packing and ensure
the safety.We will be responsible to any product damage caused on delivery.

8. Q: Do you have a guarantee of your product quality?
A: We have a guarantee of one year.
