Биметаллический термостат KSD1008 для

Категория: Refrigerator Parts >>>
Поставщик: Jinan,Retek,Industries,Inc

Цена:0,25 $ - 0,30 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.86 $*	0.49 $*
Aug-16-2025	0.20 $*	0.24 $*
Jul-16-2025	0.14 $*	0.45 $*
Jun-16-2025	0.96 $*	0.68 $*
May-16-2025	0.34 $*	0.77 $*
Apr-16-2025	0.25 $*	0.67 $*
Mar-16-2025	0.27 $*	0.79 $*
Feb-16-2025	0.15 $*	0.27 $*
Jan-16-2025	0.88 $*	0.97 $*

Характеристики

bimetal temperature controller KSD1005

bimetal thermostat KSD1008 for refrigerator

The KSD-1008 series of 3/4 (19mm) bimetal disc temperature controls from LT offers proven reliability in a moisture resistant sealed design. The snap action of the bimetal disc provides high-speed contact separation resulting in excellent life cycle characteristics at electrical loads up to 10 amps at 250VAC and 5 amps at 250VAC. The sealed design provides moisture resistance for moisture prone environments. A wide variety of terminal, lead wire and mounting configurations are available to provide maximum design flexibility. The KSD-10 is the most popular and widely applied temperature control in refrigeration applications such as defrost termination and ice cube maker control. It is also applied in a range of heat pump and air conditioning applications..

*Action characteristic: Single cutter,single throw (SPST),

*Electric rating : 250VAC@5A/250VAC@10A

*Insulation resistance : ≥100MΩ

*Action temperature range : -30℃~90℃

*Lead wire and temperature can be decided to Users requirements.

*Controls are 100% operation checked and dielectric tested.
