ASICO UL зарегистрированная 1 и 3 часа огнестойкая стальная дверь для аварийной
- Категория: Двери >>>
- Поставщик: Shandong,Asico,Door,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-19-2025 | 189.13 $* | 193.19 $* |
| Jul-19-2025 | 153.16 $* | 156.91 $* |
| Jun-19-2025 | 186.22 $* | 190.17 $* |
| May-19-2025 | 185.13 $* | 189.39 $* |
| Apr-19-2025 | 148.60 $* | 151.70 $* |
| Mar-19-2025 | 182.55 $* | 186.66 $* |
| Feb-19-2025 | 180.97 $* | 184.44 $* |
| Jan-19-2025 | 179.59 $* | 183.38 $* |
Характеристики
Product Description
ASICO door is dedicated to the manufacture of various doors, especially solutions for providing commercial hollow metal doors. ASICO door's hollow metal door is one of the flagship products, and ASICO door's hollow metal door meets US UL standards.
Product Specifications | ||
Brand | ASICO | |
Product Name | ASICO UL Listed 1 And 3 Hour Fire Rated Steel Door For Emergency | |
Standard | UL 10(b), UL 10(c), UBC 7-2, NFPA, ASTM | |
Certifications | UL NUMUBER(R38744/R38745) | |
Filler Material | Honey Core, Mineral rock wool, polyurethane. | |
Fire rated time | 1 hour up to 3 hours. | |
Size | Maximum size is 8’x8’ (2440x2440mm) | |
Door leaf sheet | 22 Ga. - 18 Ga. (0.8/1.0/1.2 mm)galvanized steel/cold roll steel | |
Door frame | 16 Ga. - 14 Ga. (1.5mm-2.0mm). cold roll steel/galvanized steel | |
Surface finish | Door leaf and frame powder coated finish. | |
Frame depth | 115mm - 240mm | |
Opening | Swing, Inward/Outward | |
Color | RAL color system, could be customized as well. | |
Accessories | Lock,handle,hinges,door closer,panic bar and other as requested. | |
Vision Panel | With or without as requested. | |
Lite Frame | UL listed lite frame. (UL Number: 38990) | |
Louver | With or without as requested. | |
Feature | Fire proof and thermal insulation. | |
Application | Suitable for building project, business, home decoration(Office, hotel, church, home and so on.) | |
Package | Inside with PE paper, outside is double layers carton box, then wooden pallets packaged. | |
MOQ | 50 sets | |
Certifications
Reinforcement&Frame
KD Frame
A KD or Knocked Down hollow metal frame (slip-on frame) is used for interior applications and comes in 3 pieces (strike jamb, hinge jamb and head). The KD metal door frame is designed to be installed after the stud wall has been built and drywall applied, as it wraps the wall. For use with metal or wood doors.
Welded Frame
Generally it has two options of face welding and a full profile welded frame.
Face welding is weld applied only to the face of the frame, usually at the 45 degree joint. The full profile weld is applied to the full contour of the frame at the intersection of the head and the jambs. Since most manufacturers can fire rate their frames knocked down (in 3 pieces), welding is not required and is usually for cosmetic appearance and ease of installation.
Face welding is weld applied only to the face of the frame, usually at the 45 degree joint. The full profile weld is applied to the full contour of the frame at the intersection of the head and the jambs. Since most manufacturers can fire rate their frames knocked down (in 3 pieces), welding is not required and is usually for cosmetic appearance and ease of installation.
Three types of common ASICO metal frames to match different options anchors.
Dry Wall Frame
Masonry Wall Frame
Adjustable Frame
More details for ASICO metal frames
* Frame steel thickness: 18 gauge (1.2mm), 16 gauge (1.5mm), 14 Gauge (2.0mm)
* Throat depth available: 4 3/4” - 10 1/4”.
* Standard height of stops shall be 0.625 in. (15.8 mm)
* Factory applied baked-on rust inhibiting primer or Prefinished.
* Cut ready opening is prepared for single stud, door silencers, three per strike jamb for single door openings, two per head for pairs, except on gasketed or weather stripped frame product. Silencers shall be supplied and installed by others.
* ASICO Frame product is mortised, reinforced, drilled and tapped at the factory for templated hardware or in accordance with the approved hardware schedule and templates provided by the hardware supplier.
* Hardware reinforcing ready for full mortised hinges and pivots, strikes, flush bolts, closer, hold open arms, and other surface applied hardware.
* Fire rated unique label 1 hour, 1.5 hour, 2 hours up to 3 hours.
* Throat depth available: 4 3/4” - 10 1/4”.
* Standard height of stops shall be 0.625 in. (15.8 mm)
* Factory applied baked-on rust inhibiting primer or Prefinished.
* Cut ready opening is prepared for single stud, door silencers, three per strike jamb for single door openings, two per head for pairs, except on gasketed or weather stripped frame product. Silencers shall be supplied and installed by others.
* ASICO Frame product is mortised, reinforced, drilled and tapped at the factory for templated hardware or in accordance with the approved hardware schedule and templates provided by the hardware supplier.
* Hardware reinforcing ready for full mortised hinges and pivots, strikes, flush bolts, closer, hold open arms, and other surface applied hardware.
* Fire rated unique label 1 hour, 1.5 hour, 2 hours up to 3 hours.
Installing Anchors
Masonry Wall Anchor
Dry Wall Anchor
Mould & Hardware
Technical Data
Factory Overview
