Машина для тиснения изготовления цветов

Категория: Фигурные дыроколы >>>
Поставщик: Wenzhou,Guangya,Machinery,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	0.98 $*	0.82 $*
Aug-17-2025	0.91 $*	0.19 $*
Jul-17-2025	0.67 $*	0.41 $*
Jun-17-2025	0.36 $*	0.12 $*
May-17-2025	0.60 $*	0.98 $*
Apr-17-2025	0.11 $*	0.18 $*
Mar-17-2025	0.16 $*	0.18 $*
Feb-17-2025	0.18 $*	0.38 $*
Jan-17-2025	0.23 $*	0.60 $*

Характеристики

embossing machine to make fabric flowers

Product Description

Automatic pressure adjustment system by servo motor, higher precision and more convenient.
Automatic decreasing pressure if no paper, extend mould service life.
Non-stop sampling function, improve work efficiency.

Max paper size	800*620mm
Min paper size	360*290mm
Max die cutting size	790*610mm
Inner chase size	880*628mm
Max working speed	8000s/h
Max stamping speed	6500s/h
Paper range	90-2000g/m²
Foil pulling shafts	longitudinal 3, transversal 2
Max foil diameter	φ220mm
Zones individually heated	10 zones (each zone can be adjusted independently, Max 200℃)
Cutting accuracy	±0.1mm
Max working pressure	200T
Gripper margin	0-17mm
Max feeding pile height	1280mm
Max delivery pile height	1070mm
Main motor power	7.5kw
Total machine power	38kw
Air requirements	0.6Mpa, >0.37m³
Machine weight	17T
Machine size	538039352445mm

Sample:

Company Information

Our Services

1. We have professional sales and engineers, are ready to send emergency repair parts in 24hours,
easily damaged parts in 5 days with professional knowledge.

2. We focus on customer service, all year non-stop service, personal training and so on.

3. Not only provide customer service, but also pre-sales system,
including solution to product selection, storage of parts, technical guidance, operating training, exchange management platform and so on.

4. Realizing the idea of focusing on customer success, creating value to customer!

FAQ

1). Q: Excuse me, are you a production company of an agent?
1): A: We are a regular production company, we have our own independent product workshop.

2). Q: What is the strength of your company?
2). A: Our company has been operating for 21 years, through continuously learning and improvement,our infrastructure of hardware and software has been greatly improved.

3). Q: What should I do if I buy your company's machine in case anything goes wrong?
3). A: All our products enjoy the benefits of one year warranty, and even send professional technicians for overseas maintenance.

4). Q: What is your company's credit standing?
4). A: Our company has obtained CE certification, and all exported products are subjected to strict customs inspection.

5). Q: If I want to buy your company's machines, can I do a field trip to your company?
5). A: Absolutely! We will arrange the time and hospitality for all foreign customers and provide the most convenient service.

Packaging & Shipping

.jpg
