ceramic fiber board

We are supply different types of ceramic fiber boards with the classification temperature of 1100, 1260, 1360 and 1430 degree centigrade. They are used as wall lining & back lining in high-temperature or heating equipments. Common size is 600X400X10~50; 900X600X30~50 or as per customers' requirements.



Ceramic fiber board adopting corresponding spun fiber  as the raw materials ,are produced by vacuum formed technology,
STA ceramic fiber board doesn't only pssess the same function of fiber but also has hard texture excellent toughness and intensity and excellent fiber resistant and heat preservation.



Ceramic Fiber Board Characters

* Low thermal conductivity
* Resistance to thermal shock

* Greater mechanical strength
* Even density ,thickness.
* Can withstand gas flow velocity of  M/SEC.
* Easy to-cut or install

* Good erosion resistance
* Shorter heat up and cool down time
* Asbestos free





	STD	HP	HA	HZ
ClassificationTemp	1260	1260	1350	1450
Working temp. (º C)	1000	1100	1200	1350
Max. Working temp. (º C)	1250	1260	1350	1450
Color	white	white	white	white
Bulk density(kg/m3)	240~300
Thermal	200º C	0.045	0.043	0.045
conductivity (W/m. k)
400º C	0.067	0.07	0.072	0.068
600º C	0.094	0.094	0.092	0.092
800º C	0.136	0.128	0.12	0.114
1000º C	0.152	0.15	0.143	0.146
1200º C	0.19	0.178	0.16	0.158
1300º C	-	-	-	0.17
Thermal shrinkage 24hrs(%)	1200º C	1260ºC	1350ºC	1400ºC
-3.3	-3.2	-3.6	-3.3
Chemical	AL2O3 (%)	45-47	47-49	53-55
composition(%)
AL2O3(%)+SiO2	97-98.5	98-99	98.5-99	83-89
ZrO2	-	-	-
Size available (mm)	Length: ≤ 1500
	Width: ≤ 1200
	Thickness: 6~50
Standard size(mm)	900x600x20~50
Tolerance (mm)	(-1, +2)

Ceramic Fiber Board Product Applications

Petrochemical process heater refractory fiber lining
Heat treating furnace or intermittent (shuttle) kiln hot face lining
General furnace backup insulation
Heat seals for kiln car or furnace door
Electrical insulator
High temperature acoustic
Fire protection



   Wood box paded with foam
