Fiber bale opening machine (BC505)
1. The machine is used to open the fiber bale and carry the fiber into fiber carding machine'belt automatically.
2. Reduce the cost, enhance the productivity.

	BC505	BC505-S
Dimensions(L*W*H)	5100*1500*2500(MM)	3500*1300*2000(MM)
Capacity	75-250kg	72-200KG
Net weight	2500kg	2000KG
power	3.75KW	3.75KW

 Fiber carding/opening machine BC1001
1.Suitable for upholstery,sofa&beddings production.To enhance competitiveness and improve working efficiency.
2.Suitable for opening all kinds of polyester short fibers(less than 100mm)Such as polyester,glue-spay cotton,with a remarkable opening rate.(99%)
3.After processing,the fiber will be very fluffy.
4.Compact structure,high productivity,long working life,low cost of maintenance.Equipped with overloading system.

Model	BC1001-360	BC1001-560	BC1001-790	BC1001-1000
Belt width	360mm	560mm	790mm	1000mm
Dimensions(L*W*H)	2140*750*940(mm)	2150*900*940(mm)	2150*1150*980mm	2150*1400*1100mm
Power	2.95kw	4.75kw	6.25kw	6.25kw
Net weight	400kg	600kg	800kg	1000kg
Capacity	60-80kg/h	120-150kg/h	160-190kg/h	200-250kg/h

Two heads filling machine with patting devices(BC502-2)

Model	Dimensions(mm)(L*W*H)	Power	Net weight	Air pressure	Capacity
BC502-2	3350*1900*1450	4.74kw	400kg	0.8Mpa	4-5pcs/min
