Inner tube sulfurator rubbber vulcanizing machine made in China
1. This Rubber vulcanizing machine & hydraulic platen tyre press rubber machine is used for all kinds of vulcanizing mould,rubber and plastic mould products,and non-mould products.
2. Being a column structure and dowward pressing trpe,the heating plate opens by the seif-weight of the heating plate,platfrom and plunger.The rising of the plunger makes the heating plate close while the hydraulic oil provides the pressure.
3. This engine base is combined together with the cylinder and base frame,which is made of ductile iron to increase the cylinder intensity and abrad ability,The cylinder is fitted with the sealing washer made of the oil-resisting rubber for the sealing purpose.
4. By moving the operational handle of the control value to the two different positions,the heating plate can open and close.
5. It uses the electric pipe for heating,thus makes the workshop clean with easy and reliable operation.
6. We can design and manufacture all kinds of no-standard rubber machinery according to the requirement of the customers.
Curing press Technical Parameter:
Type | XLB-DQ400*400*2 | XLB-DQ600*600*2 | XLB-DQ750*850*2 | XLB-DQ1000*1000*2 | XLB-DQ1500*1500*2 |
Total pressure | 0.50 MN | 1.00 MN | 1.60 MN | 4.00 MN | 8.00 MN |
Plate size | 400*400 mm | 600*600 mm | 750*850 mm | 1000*1000 mm | 1500*1500 mm |
Plate clearance | 125 mm | 125 mm | 125 mm | 125 mm | 125 mm |
Working layer nuber | 2 | 2 | 2(4) | 2(4) | 2(4) |
Piston stroke | 250 mm | 250 mm | 250(500) | 250(500) | 250(500) |
Plate pressure | 3.1 Mpa | 2.8 Mpa | 2.5 Mpa | 4.0 Mpa | 3.6 Mpa |
Motor power | 2.2 kw | 3 kw | 3 kw | 5.5 kw | 5.5 kw |
weight | 1300 kg | 3500 kg | 6500 kg | 11000 kg | 22000 kg |
Qingdao guangyue rubber machine manufacturing Co.,ltd is one of the important backbone of enterprises in rubber machinery industry in China. It is one member of Shandong Machinery Union Company. The company owns powerful technical strength, advanced tchnics, the best design and strict quality guarantee system, which owns a high reputation in China rubber machine industry.
We have long-time business relations with seveal up-gread factorys for years in China. So we can find all the rubber machine you need in condition that you purchase lots of different machines , for your convenient and the price is considerate for you .
The main products are hydraulic press, rubber mixing mill, dispersion kneader, bale cutter, rubber machine, tyre machine, inner tube press, reclaimed rubber machine and rubber powder machine,etc.
All of the products are designed visually by three-dimension cad design, quikly built module, limited element analysis, analogue action and interfering inspection with certificates: CE , ISO9001 , SGS
Our machines share the markets in whole China and most countries and areas in all world, such like Kazakhstan, Uzbekistan, Russia, the United Kingdom, the United States, Germany ,etc.
u Services of pre-sales :
1. Free Inquiry and consulting support about machine.
2. Sample send overseas support.
3. Factory visit arrangement in advance.
u Service of visit to factory and company:
1. Transportation :
We will pick you up in Qingdao liuting airport or qingdao train station with our own business car when you come.
We see you off in the airport or trian station when you leave .
2. Accommodation :
We will offer the meal for free all the time in your during time in our factory .
3. Business and language support :
We offer a Interpreter and experienced technologists around you all the time .
4. Entertainments :
I offer you free sightseeing tour in famous tourist resorts around the world in Qingdao after business talking if you like . One to two days .
In a conclude ,the only thing you need to do is pay your hotel here , other things you need not to worry about .
u Services of During-seles :
1. Design target machines up to your special requirements and send the drawing to confirm.
2. Take photos and videos to you for your information during process.
3. Documents such as packing list, commercial invoice, and bill of lading etc. will be sent in time after the delivery.
4. Free English foundation DWG, installation drawing, user guide, maintenance manual and part drawing.
5. Test Machine Before Delivery, you only need to connect the wires to the outside the control cabinet.
6. Test running: The machines must pass inspection of 3~5 hours of full load operation before leaving our factory. And we will take the video and send it to you for inspection.
u Services of After-sales :
1. Training how to instal the machine, and how to use the machine.
2. overseas technical support , door to door .
2. Warranty: 2 years after installation
All the product are CE,ISO,SGS Approved
We have customers in many countries,such as Europe and the United States,
Malaysia,Vietnam, India, South America and many other countries.
