Compressed air cylinder filling pump is an air filling device to be used for filling fresh air compressed into gas cylinder of SCBA, is designed for solving the general low pressure of compressed air.
This device output no oil, no impurities, non-toxic, tasteless, clean high pressure breathing air through purifying function of the two stages of oil-water separation and filter.
Cylinder Filling Pump can be used for firefighting SCBA, diving, shooting, emergency rescue, chemical, oil and other industries.
Diving compressor for scuba parameters
Pic.
Model
FN-100E/80E1
Working pressure
300 Bar 30Mpa 4300 Psi
Diving :225Bar 22.5 Mpa 3300 Psi
Charging rate
100L/min 6m3/H 3.5CFM
Filling time cylinder
6.8L 0-300 bar/ 20.4 min 12L 0-200 bar/ 24 min
Driven by
Three-phase electric motor
Power
3 Kw
Noise pressure
83 dB
Dry weight
40 Kg
Dimensions
650mm*350mm*360mm
Diving compressor for scuba work process
The flesh air is compressed, filtered and purified by a air compressor, after air quality analyzer qualified, into the gas bomb components. Then to inflate the cylinder safely in the explosion-proof plenum box.
Diving compressor for scuba Features
Easy to move, Easy to operate
Maintenance simple
Stainless steel interstage cooler
High pressure pneumatic hose 1.2 m.
Four-cylinder four-pole high-pressure compressor
Stainless steel fan cover
Two oil-water separator, two drain valve (optional automatic sewage)
Carbon molecular sieve filtration system
When reaches the set pressure, shut down automatically.
