Морские водяные насосы высокого давления 10
- Категория: Pumps >>>
- Поставщик: Zhejiang,Yonjou,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 488.39 $* | 512.47 $* |
| Aug-20-2025 | 484.12 $* | 508.72 $* |
| Jul-20-2025 | 406.75 $* | 426.21 $* |
| Jun-20-2025 | 476.98 $* | 500.82 $* |
| May-20-2025 | 414.27 $* | 435.85 $* |
| Apr-20-2025 | 467.19 $* | 490.17 $* |
| Mar-20-2025 | 463.22 $* | 486.77 $* |
| Feb-20-2025 | 459.75 $* | 482.65 $* |
| Jan-20-2025 | 455.9 $* | 478.42 $* |
Характеристики
Product Description
Summarize:
1. 10 HP sea water high pressure marine pump is a high-effective energy-saving product designed by YONJOU.
2. Stable running, low noise, high concentricity of components. Bearings of low noise are used for the motor, the impellers are of best dynamic and static balance, no vibration at running and the environment thus being improved.
3. No leakage. The shaft is mechanically sealed with carbide alloy wearable material, settling the serious leakage of the filling seal of a centrifugal pump and extending the duration and ensuring the operation place clean and tidy.
4. Widely used in industrial and cities’ water supply and drainage, high buildings’ booster water supply, garden's irrigation, fire-fighting booster, remote water supply, warming systems, circular booster of cold&hot water in bath rooms as well as in competitions of equipments.
5. The pump, according to the operation condition of the workshop, is vertical or horizontal, and also according to the requirements for the flow and stroke, mounted in parallel and/or in series to increase the needed flow and stroke.
6. The flow range is 1.1-2400m3/h and the stroke range is 8-160m and there are basic types, by-pass type, A B C cutting type etc. And per the different flow medium and temperature, IRG/IRGB/ISWR hot water pump, IHG/IHGB/ISWH series chemical pumps and YG/YGB/ISWB oil pumps.
Product details:
| Working Principle: | Centrifugal |
| Main applications: | Water (oil, chemical, contact us) |
| Driver: | Electric motor |
| Power Specs: | 220V/240V380/415V 3phase; 50hz/60hz |
| Max.permissible fluid temperature: | 100℃ (212°F) |
| Type of connection: | Flange |
| Casing: | Cast iron, Stainless steel |
| Impeller: | Cast iron, Stainless steel, Bronze |
| Shaft seal type: | Mechanical seal |
| Maximum drive rating: | 250KW(340HP) |
| Maximum caliber: | 500mm(20inch) |
| Maximum discharge-side pressure: | 1.6MPa(16bar) |
| Maximum head: | 160m(524.8ft) |
| Flow rate range: | 1.1-2400m3/h(4.8-10560US.GPM) |
| Pump type: | Water, Hot water type, oil type, chemical type |
Performance data:
| MODEL | CAPACITY | HEAD | EFFECIENCY | POWER |
| (m 3 /h) | (m) | (%) | (kw) | |
| 15-80 | 1.5 | 8 | 34 | 0.18 |
| 20-110 | 2.5 | 15 | 34 | 0.37 |
| 20-160 | 2.5 | 32 | 25 | 0.75 |
| 25-110 | 4 | 15 | 42 | 0.55 |
| 25-125 | 4 | 20 | 36 | 0.75 |
| 25-125A | 3.6 | 16 | 35 | 0.55 |
| 25-160 | 4 | 32 | 32 | 1.5 |
| 25-160A | 3.7 | 28 | 31 | 1.1 |
| 32-125 | 5 | 20 | 44 | 0.75 |
| 32-125A | 4.5 | 16 | 43 | 0.5 |
| 40-100 | 6.3 | 12.5 | 54 | 0.55 |
| 40-100A | 5.6 | 10 | 52 | 0.37 |
| 40-125 | 6.3 | 20 | 46 | 1.1 |
| 40-125A | 5.6 | 16 | 45 | 0.75 |
| 40-160 | 6.3 | 32 | 40 | 2.2 |
| 40-160A | 5.9 | 28 | 39 | 1.5 |
| 40-160B | 5.5 | 24 | 38 | 1.1 |
| 40-200 | 6.3 | 50 | 33 | 4 |
| 40-200A | 5.9 | 44 | 31 | 3 |
| 40-200B | 5.3 | 36 | 29 | 2.2 |
| 40-250 | 6.3 | 80 | 28 | 7.5 |
| 40-250A | 5.9 | 70 | 28 | 5.5 |
| 40-250B | 5.5 | 60 | 27 | 4 |
| 40-100(I) | 12.5 | 12.5 | 62 | 1.1 |
| 40-100(I)A | 11 | 10 | 60 | 0.75 |
| 40-125(I) | 12.5 | 20 | 58 | 1.5 |
| 40-125(I)A | 11 | 16 | 57 | 1.1 |
| 40-160(I) | 12.5 | 32 | 52 | 3 |
| 40-160(I)A | 11.7 | 28 | 51 | 2.2 |
| 40-160(I)B | 10.4 | 22 | 50 | 1.5 |
| 40-200(I) | 12.5 | 50 | 46 | 5.5 |
| 40-200(I)A | 11.7 | 44 | 45 | 4 |
| 40-200(I)B | 10.6 | 36 | 44 | 3 |
| 40-250(I) | 12.5 | 80 | 38 | 11 |
| 40-250(I)A | 11.6 | 70 | 38 | 7.5 |
| 40-250(I)B | 10.8 | 60 | 37 | 7.5 |
| 40-250(I)C | 10 | 52 | 36 | 5.5 |
| 50-100 | 12.5 | 12.5 | 62 | 1.1 |
| 50-100A | 11 | 10 | 60 | 0.75 |
| 50-125 | 12.5 | 20 | 58 | 1.5 |
| 50-125A | 11 | 16 | 57 | 1.1 |
| 50-160 | 12.5 | 32 | 52 | 3 |
| 50-160A | 11.7 | 28 | 51 | 2.2 |
| 50-160B | 10.4 | 22 | 50 | 1.5 |
| 50-200 | 12.5 | 50 | 46 | 5.5 |
| 50-200A | 11.7 | 44 | 45 | 4 |
| 50-200B | 10.6 | 36 | 44 | 3 |
| 50-250 | 12.5 | 80 | 38 | 11 |
| 50-250A | 11.6 | 70 | 38 | 7.5 |
Company Information
Zhejiang Yonjou Technology Co., Ltd is one of the leading manufacturers and exporters in the field of industry pumps with manufacturing facilities in mainland China. We are specialized in oil pump, diaphragm pump, diesel engine pump, centrifugal pump, screw pump, chemical pump etc.
