Двусторонняя радиосвязь пара комплект Retevis RT21 2 5 Вт скремблер UHF приемно-передающая

Описание и отзывы

Трекер стоимости

Характеристики









This is the newest professional analog two way radio, stylish appearance, comfortable feel, rugged enclosure, wear resistance, not easy to scratch. one meter free fall, two way radio housing without damage, the two way radio can continue to work(The bottom of the intercom down, cannot turn the knob down). Two way radio transmit poweractual test 2.5W, the actual capacity of the battery labeled.Good call quality, support for PC programming, stable and reliable quality, the use of longer.This two way radio is suitable for the storage, wharf, construction site, tourism, hotel, logistics, factory, etc.



Feature:

1.     Emergency Alarm

2.     Scanning

3.     Busy Channel Lock

4.     Wide/Narrow Bandwidth Selection (25 KHz/12.5KHz)

5.     TOT(Time-out Timer)

6.     Squelch

7.     VOX Function

8.     High/ Low Power Selectable

9.     CTCSS&DCS Encode/Decode

10.  Battery Save Function

11.  Scrambler Function

12.  English/Chinese Voice Prompt

13.  Low Battery Prompt

14.  Power Protection Function

15.  PC programming

16.  High Quality, Strong Shell, Strong Sense Of Texture



General Specification

Model Number	RT21
Frequency Range	UHF:400-480MHz
Power	2.5W
Colour	Black
ChannelCapacity	16
Battery capacity	Li-ion 1300mAh
Channel Spacing	25 /12.5KHz
Working Voltage	DC 3.7V
Working Temperature	-10°C~50°C
Mic/Speaker/Programming Port	2 pin Kenwood plug type
Antenna	SMA-F/K
Antenna Impendence	50Ω
Working Mode	Simplex
Weight Of Two Way Radio(Include battery and antenna)	7.16oz(203g)
Size Of Two Way Radio (Not include antenna)	4.76x2.44x1.22inch( 12.1x6.2x3.1cm)
Receiver
Sensitivity	≤0.2μV
Occupied Bandwidth	≤16KHz
Selectivity	≥65dB
Intermediation	≥55dB
Audio Power	1W
Audio Distortion	≤5%
Frequency Stability	5ppm
Current	80mA(when standby)220mA(when working)
Audio Response	+7~-12.5dB
Transmitter
Output Power	2.5W
Modulation Mode	16KFΦ3E
Spurious Radiation	≤7.5μW
Modulation Noise	<-40dB
Modulation Distortion	≤5%
Frequency Stability	5ppm
Maximum Deviation	≤±5KHz
Current	≤2300mA
Audio Response(300-3000Hz)	+6.5~-14dB
Adjacent Ch.power	≥65dB
Intermediation Sensitivity	8~12mV





l  2 x Portable Radio

l  2 x Li-ion battery

l  2 x Antenna

l  2 x Charger

l  2 x Belt Clip

l  2 x Sling

l  1 x User manual









 Two-way radio Pair set Retevis RT21 2.5W Scrambler UHF Two-way Radio
