Изоляционное одеяло из керамического волокна и стекловолокна 50
- Категория: Продукты из керамического волокна >>>
- Поставщик: Beijing,Coning,Building,Materials,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.35 $* | 0.79 $* |
| Aug-16-2025 | 0.9 $* | 0.9 $* |
| Jul-16-2025 | 0.63 $* | 0.62 $* |
| Jun-16-2025 | 0.8 $* | 0.46 $* |
| May-16-2025 | 0.7 $* | 0.99 $* |
| Apr-16-2025 | 0.69 $* | 0.81 $* |
| Mar-16-2025 | 0.48 $* | 0.49 $* |
| Feb-16-2025 | 0.64 $* | 0.54 $* |
| Jan-16-2025 | 0.92 $* | 0.96 $* |
Характеристики
Product Description
Ceramic Fiber glass wool Insulation Blanket for motorcycle sound insulation/50mm Ceramic Fiber glass wool Insulation Blanket
1260 C Ceramic fiber blanket/Refractory Ceramic Fiber blanket
CONING aluminum silicate ceramic fiber blanket offers 5 standard grades of spun ceramic fiber blanket,it is completely inorganic and is available in a variety of densities, thicknesses, widths and temperature ratings, all of which are lightweight and thermally efficient, resulting in a material that possesses the advantages of low heat storage and complete resistance to thermal shock.
Used in a variety of heat processing applications, the ceramic fiber blanket is produced from high strength spun ceramic fibers and is needled to provide exceptional handling strength.
♦ Needled blanket
♦ Non-combustible
♦ Low density and low thermal conductivity
TECHNICAL DATA for aluminum silicate ceramic fiber blanket
| Types(°C) | Ordinary Ceramic Fiber Blanket | Standard Ceramic Fiber Blanket | High-purity Ceramic Fiber Blanket | High Aluminia Ceramic Fiber Blanket | Zirconia Ceramic Fiber Blanket | |
| °C) | 950°C | 1050°C | 1100°C | 1200°C | 1350°C | |
| Operation Temp | (1742F) | (1922F) | (2012F) | (2192F) | (2462F) | |
| Density | 64-160 | |||||
| (kg/m3) | ||||||
| (%) | 950°Cx24h | 1050°Cx24h | 1100°Cx24h | 1200°Cx24h | 1350°Cx24h | |
| Permanent Change on Heating | ≤-3 | ≤-3 | ≤-3 | ≤-3 | ≤-3 | |
| 0.15 | 0.12 | 0.12 | 0.12 | 0.16 | ||
| W/(m·k)(128kg/m3) | (600°C) | (600°C) | (600°C) | (600°C) | (800°C) | |
| Theoretic Heat Conductive Co-efficient | 0.22 | 0.20( | 0.2 | 0.2 | 0.2 | |
| (800°C) | 800°C) | (800°C) | (800°C) | (1000°C) | ||
| (Mpa) | ≥0.04 | ≥0.05 | ≥0.05 | ≥0.04 | ≥0.06 | |
| (25mm) | ||||||
| Tensile Strength | ||||||
| (Thickness 25mm) | ||||||
| Al2O3(%) | 44 | 45-46 | 47-49 | 52-55 | 39-40 | |
| Chemical | Al2O3+SiO2(%) | ≥96 | ≥98 | ≥99 | ≥99 | - |
| Composition | ZrO2(%) | - | - | - | - | 15-17 |
| Al2O3+SiO2 | - | - | - | - | ≥99 | |
| +ZrO2(%) | ||||||
| Fe2O3(%) | ≤1.0 | ≤0.8 | ≤0.2 | ≤0.2 | ≤0.2 | |
| Na2O+K2O(%) | ≤0.4 | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.2 | |
| CaO+MgO | ≤0.3 | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 | |
