Сертификация BV горячая Распродажа немецкий двигатель генератор газовой турбины 10 кВт-50
- Категория: Генераторы газовых турбин >>>
- Поставщик: Kanpor,Electrical,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.12 $* | 0.19 $* |
| Aug-20-2025 | 0.82 $* | 0.75 $* |
| Jul-20-2025 | 0.64 $* | 0.74 $* |
| Jun-20-2025 | 0.94 $* | 0.21 $* |
| May-20-2025 | 0.45 $* | 0.29 $* |
| Apr-20-2025 | 0.67 $* | 0.52 $* |
| Mar-20-2025 | 0.26 $* | 0.91 $* |
| Feb-20-2025 | 0.88 $* | 0.76 $* |
| Jan-20-2025 | 0.99 $* | 0.54 $* |
Характеристики
Voltage Available:
50Hz: 380-400-415V/220-230-240V;
60Hz: 220-380-416-440-480V/110-208-220-240V
Any special voltage is also available as client’s request
Prime Power:
Comply with GB/T2820-97(eqv.ISO8528).
Genset can run unlimitedly under certain power range.
One hour 10% over load in every 12 running hours is allowed;
Standby Power:
standby power is the limit value of maximum output for emergency use.
It is off-oil power,overloading is prohibited
♦ Genset Specification:
| Genset Model | KPD65-PN | ||
| Prime power (KW/KVA) | 48/60 | Standby Power (KW/KVA) | 52/65 |
| Voltage(V) | 400/230 | Rated Speed (RPM) | 1500/1800 |
| Frequency (Hz) | 50/60 | Rated Current (A) | 86.4 |
| Connection | 3 phase 4 wire | Power Factor: | 0.8 |
| Weight (kgs) Open Type | 1250 | Weight (kgs) Silent Type | 1650 |
| Dimensions (mm) Open Type | 2400*860*1300 | Dimensions (mm) Silent Type | 2800*1100*1500 |
♦ Engine Specification:
| Engine Model | D226B-6N |
| Engine Power | 55KW |
| Cylinder-Bore*Stroke | 6-105*120mm |
| Displacement(L) | 6.234 |
| Air intake way | Naturally aspirated |
| Fuel control | Oxygen sensor closed loop control |
| Starting method | DC Electric start |
| Governor | Electronic speed governing |
| Cooling method | Closed-loop water cooling |
| Compression Ratio | 11.5:1 |
| Oil Consumption(g/KW.h) | 1.08g/KW.h |
Why Choose Us
Diesel generator set/Gas generator set/Alternator: 12 months from shipment date.
Gasoline generator set:6 months from shipment date.
Spare parts:3 months from shipment date.
Factory Inspection: the test items before delivery are mainly as follows:
1.Each genset shall be put into commission more than 4 hours totally. They are tested on idle load, fully
load and 10% overload;
2.The noise level is tested
3.All of the meters on the control panel shall be tested
The appearance of the genset and all of the label and nameplate shall be checked
Ask product operation details, please consult the sales staff by e-mail or Trademanager.
Φ What to know more?
Click here:Home >>All Products>> and Contact us!
FAQ
1.What's your power range of Generators?
Answer: We can offer the range from 1kva~1250kva.
2.What's your delivery time?
Answer: Generally,we can delivery in 15-30 days after we get the deposit.
3.What's your payment?
Answer: We accept T/T ,and 30% as the deposit,the balance payment should be paid before delivery the goods.
4.What's your warranty?
One year or 1000hours (accord to whichever reach first) from Ex-Factory date
5.What's your MOQ?
Answer:We accept small power generator MOQ is 10 or 20 sets .Other accept 1 set.
