High purity oxygen zeolite molecular sieve 13X HP for PSA concentrator oxysiv 5xp oxygen enrichment molecular sieve
Product Description
Chemxin Molecular Sieve 13X HP is equal to jalon molecular sieve jlox-500. It is mainly used in PSA oxygen concentrators and oxygen concentrators device, and as well as the industrial PSA unit, with the characteristics of higher N2 adsorption capacity and N2 with O2 selectivity, easy desorption and etc.
Technical Parameter:
Model
13X HP
Color
Light gray
Nominal pore diameter
10 angstroms
Shape
Sphere (ball)
Diameter (mm)
0.4-0.8
1.6-2.5
Loss on Ignition (wt%.575℃, 1hr)
≤1.0
≤1.0
Bulk density (g/ml)
≥0.62
≥0.62
Crushing strength (N)
/
≥30/piece
Static H2O capacity (wt% RH60%,25℃)
≥30
≥30
Static CO2 capacity(wt% 250mmHg, 25℃)
≥19.8
≥19.8
Attrition (wt%)
≤0.2
≤0.2
Particle Ration (%)
≥95
≥97
N2 capacity(ml/g,)
≥8
≥8
N2/O2 Selectivity(a,)
≥3
≥3
Hand & Storage Recommendation: It should be handled to avoid generation of dusty conditions at the workplace. Storage in a dry warehouse is recommended. Open packages should be resealed to prevent contamination and adsorption of water or other gases and vapors. The material in bag-in-box should be used within 12 months,while bag-in-steel drum should be used within 24 months.
Attention: To avoid damp and pre-adsorption of organic before running, or must to be reactivated.
Related Products
4A molecular sieve for water removal
Model
4A
Color
Light gray
Nominal pore diameter
4 angstroms
Shape
Sphere
Pellet
Diameter (mm)
1.7-2.5(8*12 mesh)
3.0-5.0(4*8 mesh)
1.6(1/16 inch)
3.2(1/8 inch)
Size ratio up to grade (%)
≥98
≥98
≥96
≥96
Bulk density (g/ml)
≥0.70
≥0.70
≥0.68
≥0.68
Wear ratio (%)
≤0.20
≤0.20
≤0.40
≤0.40
Crushing strength (N)
≥35/piece
≥85/piece
≥30/piece
≥70/piece
Static H2O adsorption (%)
≥21.5
≥21.5
≥21.5
≥21.5
Static methanol adsorption (‰)
≥15
≥15
≥15
≥15
Water content (%)
≤1.5
≤1.5
≤1.5
≤1.5
Typical Chemical Formula
Na2O . Al2O3 . 2SiO2 . 4.5 H2O
SiO2 : Al2O3 ≈2
Typical Application
a) Drying and removing of CO2 from natural gas, LPG,air, inert and atmospheric gases, etc b) Removal of hydrocarbons, ammonia and methanol from gas streams (ammonia syngas treating). c) Special types are used in the airbreak units of buses, trucks and locomotives. d) Packed in small bags, it may be used simply as a packaging desiccant.
