Length 30-75mm screw spike making machine for producing nail



 Length 30-75mm screw spike making machine for producing nail

Nail making machine is used for producing various normal nails and special

nails.It  is fully automatic, high efficiency, easy to operate, and durable.You

can choose any length and diameter you need.The nail producing line: steel

wire - wire drawing machine - nail making machine - Polishing machine- Coil

nail machine

Maintain:

1.Dont adjust when the nail making machine is working.

2.Keeping the nail knife sharp.

3.Before fix the nail making machine, please turn off the power.

4.It should lubricate mass around 15 days when running the machine and

Please lubrication the nail making machine in regular.

Technical parameter	A-711	A-712	A-713	A-714	A-715
Dia of nail max (mm)	1.6	2.8	3.1	4.5	6
Dia of nail min (mm)	0.9	1.2	1.8	2.8	4.1
Length of nail max (mm)	25	50	70	100	150
Length of nail min (mm)	9	16	30	50	100
Designed output (/min)	450	300	280	260	220
Motor power (kw)	1.5	2.2	3	4	10
Speed (psc/min)	1380	1430	1430	1430	1430
Weight (kg)	1200	1450	1800	2000	3500
Overall dimension (mm)	1500*1300*1200	1700*1300*1400	2000*1400*1400	2200*1600*1650	3220*1838*1545



 Length 30-75mm screw spike making machine for producing nail

Wooden case packing with seal belt.





Length 30-75mm screw spike making machine for producing nail

1. Pre-sale services:

Act as a good adviser and assistant of clients enable them to get rich and generous returns on their investments.

1>. Select equipment model;

2>. Design and manufacture products according to clients' special requirement;

3>. Train technical personnel for clients.

2. Services during the sale:

1>. Pre-check and accept products ahead of delivery;

2>. Help clients to draft solving plans.

3. After-sale services:

Provide considerate services to minimize clients' worries.

1>. Assist clients to prepare for the first construction scheme;

2>. Install and debug the equipment;

3>. Train the first-line operators;

4>. Examine the equipment;

5>. Take initiative to eliminate the troubles rapidly;

6>. Provide perfect service;

7>. Provide technical exchanging





 Zhengzhou Cambrian Machinery & Electronic Co.,Ltd . have been designing, developing, manufacturing and marketing Machinery for more than 10 years.
After these years of development, we have high quality professional teams, skillful talents,

strong technical force, strong and independent research and development capabilities,

advanced production equipment and a perfect aftersales service system. So choose us,

equaling to choose the competitive price and stable quality both.
