Литий-диоксид серы WR34615 2 9 V 8000mAh 34615 8.0Ah LiSO2 d
- Категория: Основной батареи >>>
- Поставщик: Shenzhen,Everwin,Tech,Co.,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.23 $* | 0.8 $* |
| Aug-16-2025 | 0.40 $* | 0.37 $* |
| Jul-16-2025 | 0.49 $* | 0.88 $* |
| Jun-16-2025 | 0.40 $* | 0.83 $* |
| May-16-2025 | 0.38 $* | 0.77 $* |
| Apr-16-2025 | 0.22 $* | 0.95 $* |
| Mar-16-2025 | 0.15 $* | 0.76 $* |
| Feb-16-2025 | 0.22 $* | 0.28 $* |
| Jan-16-2025 | 0.91 $* | 0.75 $* |
Характеристики
Everwin Technology Limited has specialized in LiSO2 battery . We can provide all models.
WR34615 2.9V 8000mAh LiSO2 Battery
1. Specification:
Lithium Sulfur Dioxide (LiSO2) Battery delivered a voltage of 2.9V. The batteries have a high energy density and a good capability for delivering repeated bursts of high power.
This kind of cell is mainly used in defense applications, utility metering and etc.
| GB | IEC | size(mm) | weight(g) | voltage(v) | cut off volt(v) | capacity(mah) | Operating Current Max.(mA) | Pulse current (mA) | Operating temperature (℃) |
| WR14505 | AA | 14.5×50.5 | 20 | 2.9 | 2.0 | 1100 | 100 | 1000 | -40~+75 |
| WR17335 | 2/3A | 17.0×34.5 | 15 | 2.9 | 2.0 | 800 | 200 | 750 | -40~+75 |
| WR17505 | A | 17.0×50.5 | 30 | 2.9 | 2.0 | 1500 | 500 | 1500 | -40~+75 |
| WR20590 | 20.0×59.0 | 40 | 2.9 | 2.0 | 2000 | 200 | 1000 | -40~+75 | |
| WR26500 | C | 26.2×50.0 | 50 | 2.9 | 2.0 | 3800 | 1000 | 2000 | -40~+75 |
| WR26600 | 5/4C | 26.2×60.0 | 60 | 2.9 | 2.0 | 5000 | 1000 | 2000 | -40~+75 |
| WR34615 | D | 34.2×61.5 | 100 | 2.9 | 2.0 | 8000 | 2000 | 5000 | -40~+75 |
| WR38500 | “fat” D | 38.5×50.0 | 110 | 2.9 | 2.0 | 9500 | 2000 | 5000 | -40~+75 |
| WR411400 | “fat”DD | 41.5×141.0 | 280 | 2.9 | 2.0 | 35000 | 5000 | 8000 | -40~+75 |
2.Key Features:
Great output, steady operation voltage and safety.
OCV is between 2.9~3.0V, operation voltage would be changed with different loads 2.6~2.8V), cut off voltage is 2.0V
Wide temperature range of operation from -40℃ to 75℃.
Suited for large current continuous discharge and pulse discharge.
Excellent shelf life (10 years), low self-discharge (1% or less per year).
3. Applications:
Alarms and security wireless devices
Mobile asset tracking
Electronic Meters (Water, Gas, Electricity)
Professional electronics
4. Our Factory:
