OPTO-EDU A23.1503 2K 3 8 M HD USB большая подставка светодиодная кольцевая подсветка цифровой электронный Usb стерео Мобильный
- Категория: Microscopes >>>
- Поставщик: Opto-Edu,(Beijing),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 186.86 $* | 195.45 $* |
| Aug-15-2025 | 184.61 $* | 193.9 $* |
| Jul-15-2025 | 154.75 $* | 162.79 $* |
| Jun-15-2025 | 181.15 $* | 190.77 $* |
| May-15-2025 | 158.94 $* | 166.86 $* |
| Apr-15-2025 | 178.73 $* | 187.99 $* |
| Mar-15-2025 | 176.49 $* | 185.32 $* |
| Feb-15-2025 | 175.69 $* | 184.52 $* |
| Jan-15-2025 | 173.91 $* | 182.1 $* |
Характеристики
Head: Trinocular Head, Both Eye Tube Diopter Adjustable
Light Split Switch E100:P0/E0:P100
With Eyepiece Adapter + 1.0x C-Mount
Eyepiece: WF10x/20mm, Both With Eye-cup\t
Zoom Lens: 0.7~4.5x\t
Zoom Ratio: 1:6.5\t
Magnification: 7x-45x, Up To 3.5x-180x With Optional Eyepieces And Auxiliary Lens\t
W.D.: Working Distance100mm, With Standard 1.0x Lens\t
F.O.V: Field Of View 1~95.2mm\t
Stand: Large Pole Stand, Size 480x320mm, Pole Height 240mm, Dia.32mm, With Heat Resist Soft Rubber Pad, Working Area For Phone PCB Repair
Light Split Switch E100:P0/E0:P100
With Eyepiece Adapter + 1.0x C-Mount
Eyepiece: WF10x/20mm, Both With Eye-cup\t
Zoom Lens: 0.7~4.5x\t
Zoom Ratio: 1:6.5\t
Magnification: 7x-45x, Up To 3.5x-180x With Optional Eyepieces And Auxiliary Lens\t
W.D.: Working Distance100mm, With Standard 1.0x Lens\t
F.O.V: Field Of View 1~95.2mm\t
Stand: Large Pole Stand, Size 480x320mm, Pole Height 240mm, Dia.32mm, With Heat Resist Soft Rubber Pad, Working Area For Phone PCB Repair
Trinocular Head, Both Eye Tube Diopter Adjustable
Light Split Switch E100:P0/E0:P100
With Eyepiece Adapter + 1.0x C-Mount
Light Split Switch E100:P0/E0:P100
With Eyepiece Adapter + 1.0x C-Mount
Zoom Lens: 0.7~4.5x\t
Focusing Range 50mm, Distance To Center 155mm
Total Magnification Up To 3.5x-180x With Optional Eyepieces And Auxiliary Lens
Upper 56 LEDs Right Light Brightness Adjustable
Large Pole Stand, Size 480x320mm, Pole Height 240mm, Dia.32mm, With Heat Resist Soft Rubber Pad, Working Area For Phone PCB Repair
A23.1503 DIY Phone PCB Repair Microscope | ||||
Head | Trinocular Head, Both Eye Tube Diopter Adjustable Light Split Switch E100:P0/E0:P100 With Eyepiece Adapter + 1.0x C-Mount | |||
Eyepiece | WF10x/20mm, Both With Eye-cup | |||
Zoom Lens | 0.7~4.5x | |||
Zoom Ratio | 1:6.5 | |||
Magnification | 7x-45x, Up To 3.5x-180x With Optional Eyepieces And Auxiliary Lens | |||
W.D. | Working Distance100mm, With Standard 1.0x Lens | |||
F.O.V | Field Of View 1~95.2mm | |||
Stand | Large Pole Stand, Size 480x320mm, Pole Height 240mm, Dia.32mm, With Heat Resist Soft Rubber Pad, Working Area For Phone PCB Repair | |||
Optional Accessories | Cata.No. | |||
Eyepiece | WF15x/15mm, High-eyepoint | A51.1520-15 | ||
WF20x/10mm, High-eyepoint | A51.1520-20 | |||
Auxiliary Lens | 0.5x,W.D. 177mm | A52.1520-05 | ||
0.75x,W.D. 120mm | A52.1520-75 | |||
2.0x,W.D. 30mm | A52.1520-20 | |||
Light Source | Upper 56 LEDs Right Light Brightness Adjustable | A56.2103-A | ||
Digital Camera | HDMI+USB+TF Digital Camera, 38.0M, USB Measure | A59.4231 | ||
7" LCD Digital Camera, AV Output | A59.5107 | |||
9" LCD Digital Camera, AV Output | A59.5109 | |||
CCD Adapter | Eyepiece Adapter + 0.5x C-Mount | A55.1520-05 | ||
A23.1503 Zoom Stereo Microscope Optical Data Sheet | ||||||||||||||||
Objective | Standard 1.0x | Auxiliary 0.5x | Auxiliary 0.75x | Auxiliary 2.0x | ||||||||||||
W,D. | 100mm | 177mm | 120mm | 30mm | ||||||||||||
Eyepiece | Mag | View Field | Mag | View Field | Mag | View Field | Mag | View Field | ||||||||
10X/20mm | 7.0X | 28.6mm | 3.5X | 57.1mm | 5.25x | 43.8mm | 14X | 14.3mm | ||||||||
45.0X | 4.4mm | 22.5X | 8.9mm | 45x | 6.5mm | 90X | 2.2mm | |||||||||
15X/15mm | 10.5X | 21.1mm | 5.25X | 42.8mm | 7.87x | 31.8mm | 21X | 10.7mm | ||||||||
67.5X | 3.3mm | 33.75X | 6.7mm | 50.6x | 4.7mm | 135X | 1.7mm | |||||||||
20X/10mm | 14.0X | 14.3mm | 7.0X | 28.6mm | 10.5x | 23.9mm | 28X | 7.1mm | ||||||||
90.0X | 2.2mm | 45.0X | 4.4mm | 67.5x | 3.6mm | 180X | 1.1mm | |||||||||
