Лучшая цена Высокое качество topcon цифровой уровень 2LS orion общая

best price high quality topcon digital level 2LS orion

• Fast Automatic Measurement
• Highly Accurate Measurements
• Increased Productivity up to 50%

SPECIFICATIONS:

• Accuracy (height): ±2.0mm at 30m
• Accuracy (distance): ±10mm  at  10m
• Working range (Tape staff): 0.9 to 30m (2.9 to 98ft)
• Working Range (Aluminum Staff): 2.0 to 50m (6.5 to 164ft)
• Measuring time: <2sec
• Self-compensation range: ±12°
• Telescope Length: 206mm
• Magnification: 20X
• Objective aperture: 30mm (1.18in.)
• Resolving power: 4.5"
• Field of view: 1°20'
• Minimum focus: 0.9m (2.9ft)
• Image: Erect
• Stadia ratio: 1:100
• Stadia constant: 100
• Compensator: Type Pendulum compensator with magnetic damping system
• ±12'
• Height Accuracy: Electronic reading ±2.0mm at 30m
• Height Accuracy: Optical reading ±2.0mm at 30m
• Tape staff: BCX 0.9 to 30m (2.9 to 98ft)
• Aluminium staff: BAS 2.0 to 50m (6.5 to 164ft)
• Measuring time: <2sec
• Least count: 0.001m, 0.01ft
• Minimum light for measurement: 20lx. at staff surface
• Accuracy to Aluminium staff: BAS :D<=10m ±10mm, 10mLeast count: 0.01m, 0.1ft
• Display: 7 segment and character LCD with backlight
• Keyboard: 6 keys (5 on front panel, 1 on side)
• Circular level sensitivity: 8'/2mm
• Measurement Program: Single/Continuous/Elevation/Height difference
• Water and dust resistance: IP55 Category2
• Operating temperature: -20℃ to +50℃
• Power supply: AA dry cells x 2
• Operating time: 120hrs = 50,000 points (at +20℃, point every 5 sec)
• Weight: 1.8kg (include batteries)
• Size: 206 x 123 x 137mm

Shanghai Galxy International Trade company, Ltd. combining with developing, researching and producing. Our company is located in Pudong Developing Zone, and has two subsidiary companies: Shanghai Galaxy International Trade Co., Ltd. and Mato Opto-electrical High-tech Company. Our company has researching center and factory in Changzhou.

Our main products are as following: total station, electronic theodolite, automatic level, laser level, rotation laser, GPS, distance laser sensor and accessories, such as tripod, prism, pole, staff and USB cable for total station. Our company designs software for many domestic and oversea factories, for example, Boif, TJOP, Stanley, and Cst-Berger. We have powerful capacity in technical research, and the products we designed have advanced technology and steady performance. The non-prism total station and the absolute coding measure instrument we developed and produced have very competitive points in the measure instrument market.

We expect that we could cooperate with more business partners from all over the world. In addition, we can do OEM service for companies or dealers that want to find better producers in China.

Our goal is to produce the best surveying instruments in the world.

Our target is to globalize the market, internationalize the quality and maximize the profit!
