 Price of Hot Air PVC Vinyl Welder Ventilation Ducting Tube Making Machine

Model No.: DR-V1800

This machine is specifically designed to weld flexible reinforced ducting. This machine will add a wire cord on the ducting in heliciform and easily add a strip to the outside.



 Machine Features:



QUALITY & RELIABILITY

1. Lean manufacturing principles
2. Solid steel frame design
3. Designed and built for multiple decade use
4. Built for multiple shift production
5. Low maintenance for extended up time
6. First and last machine you will need for welding



Ventilation Ducting Tube Making Machine
Heater Power		1800 W
Power Consumption		3.5 KW
Voltage		AC 220 V  50/60 Hz
Rated Current		15 A
Speed		2-10 m/min
Working Pressure		3-6 KG/cm²
Upper Roller Pressure		0.5-4.5 KG/cm²
Width of roller		10-60 mm
Width of hot air nozzle		10-60 mm
Wire Cord Diameter		Max 8 mm
Ducting Size		Diameter less than 1600 mm
Upper roller lift		15-25 mm
Throat length		850 mm
Temperature		up to 750 ℃
Gross weight		1340 KG
Packing Dimension		A: L*W*H=3100*1230*2160 mm B: L*W*H=2900*750*1700 mm



Welding Types of the Ventilation Ducting Tube Making Machine









Application of Ventilation Ducting Tube Making Machine







* Quality is our culture

* Competitive Advantages

* Market Niche

* Trustworthy Supplier



Question: How do we pack the machine?
1.The machine will be packed with strong plywood case(export standard, no need additional fumigation)
2.Fragile parts will be seperately packed with cushion packing material



Question: How about the installation and trainning?
1.Most machines will be packed with no take apart, it comes to be a complete machine; You can start the operation with connect power and air compresor.
2.For other cases, videos and manul book will be sent for the installation.
3.Parameters will be set up before delivery. Customer will do little adjustment.
4.Overseas service is available



Question: How about the after sale service
1.All our machines is one year warranty, spare parts will be freely provided within 12 months
2.We have all spare parts in stocks
3.12-24 hours Online service by Email or Video Online for basic setup and repairs
4.Engineer overseas service is available.



Question: Do you have the customized service?
1.The voltage of the machine can be 110/220/380/440V, 50/60 Hz. Please confirm us the voltage details when place an order
2.The color of the machine can be customized, please send us the color sample
3.The function of the machine can be customized, such as: PLC control, auto-turntable, robotic, etc



Question: Could you make die / mould for me, if I buy machine from you?
We make mould/die up to the products. We will need samples or drawings to be sent for making moulds.



Improve your operations, increase production speed, improve accuracy and maximize product demands with any of our welders designed specifically for your needs. Let us help you choose or build the right machine for your application.
