Новые модули дисплея XBTN400
- Категория: Instrument Parts & Accessories >>>
- Поставщик: Kailiyuan,Electronic,Technology,(shenzhen),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.60 $* | 0.68 $* |
| Aug-16-2025 | 0.83 $* | 0.51 $* |
| Jul-16-2025 | 0.83 $* | 0.81 $* |
| Jun-16-2025 | 0.74 $* | 0.38 $* |
| May-16-2025 | 0.92 $* | 0.36 $* |
| Apr-16-2025 | 0.68 $* | 0.49 $* |
| Mar-16-2025 | 0.69 $* | 0.43 $* |
| Feb-16-2025 | 0.18 $* | 0.91 $* |
| Jan-16-2025 | 0.71 $* | 0.68 $* |
Характеристики
XBTN400 XBT-N400 Magelis Display Modules new
Main
| Range of product | Magelis XBTN |
Product or component type | Small panel with touchscreen and keypad | |
Display type | Extra-bright matrix backlit LCD | |
Display colour | Green | |
Display resolution | 122 x 32 pixels | |
Messages display capacity | 1 line of 5 characters minimum | |
[Us] rated supply voltage | 5 V DC | |
Supply | From PLC (terminal port) | |
Software type | Configuration software | |
Software designation | Vijeo Designer Lite | |
Operating system | Magelis | |
Downloadable protocols | Modbus Uni-TE | |
Complementary | Character font | ASCII Chinese (simplified Chinese) |
Number of key | 8 | |
Number of fixed keys | 4 | |
Number of customisable keys | 4 | |
Number of pages | 200 application pages 256 alarm pages | |
Memory type | Flash | |
Memory capacity | 512 kB | |
Integrated connection type | Serial link female RJ45 asynchronous RS232C/RS485 point to point | |
Realtime clock | Access to the PLC real-time clock | |
Product mounting | Flush mounting | |
Fixing mode | By 2 spring clips | |
Display material | Polyester | |
Front material | PPT | |
Keypad material | Polyester | |
Marking | CE | |
Width | 132 mm | |
Height | 74 mm | |
Depth | 43 mm | |
Cut-out dimensions | 119.4 (+/- 0.5) x 63 (+/- 0.4) mm | |
Product weight | 0,36 kg | |
Environment | Standards | CSA C22-2 No 14 IEC 60068-2-27 |
Product certifications | ATEX zone 2/22 CSA Class 1 Division 2 | |
Ambient air temperature for operation | 0...55 centigrade degree | |
Ambient air temperature for storage | -20...60 centigrade degree | |
Relative humidity | 0...85 % without condensation | |
IP degree of protection | IP20 rear panel IEC 60529 | |
NEMA degree of protection | NEMA 4X front panel outdoor use | |
Shock resistance | 15 gn 11 ms | |
Vibration resistance | 1 gn 8,45...150 Hz +/- 3.5 mm 2...8,45 Hz | |
RoHS EUR conformity date | 0651 | |
RoHS EUR status | Compliant |
