XB-3120 1D Лазерная Всенаправленный сканер штрих-кода USB для

Описание и отзывы

Трекер стоимости

Характеристики





below are some advantages of the product :

1:Ergonomically design :comfortable and convenient operate



2:longevity and shock resistance:5 million times button life and 2m drop onto concrete



3:Faster and accurate scaning ,and powerful decoding



4:simple and easy set ,and online update supported



5:factory supply directly & 10 years manufacture experiences



Features :

1)Support both omni-directional and single-line scan

2)20 laser scan line make the scan rate up to 1500 scan/s and 5directional scan

3)self-developed decoder chip and high performance omni-directional barcode scanner

4)hardware decode technology omni-directional  barcode scanner

5)Support Keyboard, RS-232, USB interface port.

6)Support more than 20 countries' keyboard output.



Hot selling barcode scanner :



Mini portable scanner         Fixed Mounted scanner             laser Barcode Scanner





Tech-parameters :



Features	Description
Light source?	High performance laser diode 650nm
Beeper Operation	Programmable tone & volume
CPU	32Bit hardware decoder
Scanning mode	20scan lines ,5 directional scanning
Scan type	Omnidirectional and 20 line scanning
Visual Indicators	Two color LED (blue & red)
Depth of Field	0-220mm for 0.33mm UPC/EAN 100%
Interface	USB.RS232,Keyboard wedge
scanning speed	1500scans/second
scanning lines	20lines
Minimum resolution	0.127mm(5mil)@Code 39, PCS=90%
Printe contrast	>30%(UPC/EAN 100%)
Physical
Dimemsion	155*150*75mm
weight	680g
cable length	2M
Electrical
Input Voltage	5VDC ± 10%
Operating current	270mA
Standby power?	1.0watts
Safety
Laser Class	CDRH class II,IEC 60825-1 class 1
EMC	CE EN55022 B, FCC Part 15 Class B, VCCI, BSMI
Environmental
Operating temperature	0 ° C~50 ° C(32 ° F-122 ° F)
Operating humidity	5%~95%relative humidity, non-condensing
Storage temperature	20 ° C~+60 ° C(-4 ° F-140 ° F)
Light Levels	4500Lux
Drops	Designed to withstand 1.0m drops
Decode capability	UPC/EAN/JAN, UPC/EAN with supplementary, JAN 8& JAN 13 ISBN/ISSN, EAN,Code 39, Code 39 with full ASCII, Code 93, Code 128,Codabar (NM7),trioptic Code 39, MSI/Plessy, Interleaved 2 of 5 (ITF), Addendum 2 of 5,IATA Code,China Postal Code, Code 32, Industrial 2 of 5, Standard 2 of 5,discrete2 of 5,Matrix 2 of 5, Code 11, UPC/EAN RSS, RSS ar
