                                      GSM ultrasonic water meter

Application:

GENERAL

The water meter is adapted by the company's newly-developed unique advanced transit time measurement technology, with remarkable features of low power consumption, wide measuring range ratio, stable and reliable measurement. In the structure, the components take the IP68 program, that is, each component is of an IP68 protection level, to ensure long time operation though water in the inside meter. The wireless power and various communication interfaces can be matched to the meter to achieve remote meter reading.



♦ KEY FEATURES

1 Double beam ultrasonic sensors for high accuracy and reliable operation
2 Less than 0.01 m/s starting velocity
3 Multi line 9 digital LCD accumulative flow and 4 digital for instantaneous flow
4 Support MODBUS, M-BUS, HART communication protocol
5 Built-in batch controller and time accumulator
6 Built-in Lithium battery for 6 years life expectancy

7 Output: Two way isolated pulse output (pulse equivalent and output pulse can be

arbitrary programmed); two-wired system 4-20mA output



♦SPECIFICATIONS

Item	Specification
Standard	ISO4064-2005, GBT778-2007
Measurement Liquid	Water, sewage, seawater(other liquid need to customized) liquid should be full of pipeline
Medium Temperature	0.1~30 ℃
Working Environment	Temperature: -10~45 ℃; Humidity ≤100%(RH)
Working Pressure	1.6MPa(2.5MPa optional)
The sensitivity of upstream	U3
THe sensitivity of downstream	D0
Climatic and mechanical	C Class
Electromagnetic compatibility class	E2 Class
Communication Interface	RS485/USART/Infrared
Output Signal	2 way OCT pulse output/TTL pulse output/One way 4~20mA output
Power supply	Built-in Lithium battery(3.6,19AhV)/DC8~36V power supply
Protection Class	IP68, can work 2 meters under water
Digital Display	Multi line 9 digital accumulative flow, 4 digital display for instantaneous flow, varies of state prompt and units.
Data Storage	EEPROM/FLASH, automatically record the accumulative flow of last 512 days
Measurement cycle	Measuring: 1 times/second; Verification: 4 times/second
Power Consumption	≤2.7AH/year, 6 years battery life
