large diameter rock drill bit directional drilling hole opener/assembled bit for water well drilling

Product Description



Our hole opener bit advantage
1.Straighter Holes: By drilling a smaller hole with a"pilot"bit, then attaching that said bit onto the buttom of the hole opener. The hole opener will follow the path of the hole drilled by the smaller bit.
2.Larger holes with smaller rigs: By drilling a hole in stages, larger holes can be drilled with smaller rigs, A smaller hole requires less power.
3.Replacing cutters and cutting cost: on most hole opener designs, the cutters can be easily replaced, The cost to replace a cutter is a fraction of the cost to replace a large tricone rock bit.
4.Cost of large rock bit: Larger diameter rock bits not only cost a lot, they can be difficult to find, A more economic solution is to use a hole opener that uses smaller tricone rock bit segments.
5.Flexability:Hole openers can be fabricated in just about any size, and can be configured to drill through any formation.HDD hole opener drill bit for water well drilling.



Recommended Drilling Parameter

IADC
WOB
(KN/mm)
RPM
(r/min)
Applicable Formations
517/537
0.4~1.0
120~60
Soft formations with low compressive strength and high drillability, such as mudstone, gypsum, salt, soft limestone, etc.
 617
0.45~1.1
90~50
Medium hard formation with high compress strength, such as hard shale, limestone, sandstone, dolomite. etc
637
0.5~1.2
80~40
Hard formations with high compressive strength, such as sandstone, limestone, dolomite ,hard gypsum, marble, etc.
117/127
0.35~0.9
150~70
Soft to medium formations with low compressive strength , such as medium soft shale, hard gypsum, medium soft limestone, medium soft sandstone, soft formation with harder interbed, etc.
Note: The upper limits of WOB and RPM in above table should not be used simultaneously.

Hole opener

1>    newest TCI tricone bit

2>    API kingdream bit, type: Milled tooth&TCI tricone bits

3>    a large stock

4>    High temperature and wear resistance, fast drilling rate

5>    high penetrating power and durability stuiable for different rock formation, reliable bearing system

6>    IADC code suitable for different formation

7>    Sizes range from 3 7/8" to 26".

8>    Best prices and great quality

9>    top quality products and excenllent service

10> about 30 years experience in tricone bits

11> used for water well, mining and oilfield drilling



Product Show



1111


HTB1hUYRGFXXXXbrXFXXq6xXFXXXk



Packaging & Shipping

wooden box or as your request


Company Information



We are Hejian Deris Petroleum Drilling Equipment Co., Ltd.

Our factory specializes in supplies tricone drill bits, PDC bit,hole opener bit,diamond core bit,single drill bit,tricone bit cutter,PDC cutter,drill pipe, drill collar etc to all over the world.bits size from 2 7/8" to 26",and cover almost all IADC codes.

It can be used in various os different fields:mining,underground exploration,water well drilling,oil and gas well drilling.This type of bits have optimal bearing disign,it can be working stably in high WOB,the high quality tungsten carbide inserts on cone the gauge make a good wear resistance can extend the woking life of bit.Our purpose is to sell the best quality products at the lowest possible price.


 The principle of our company is based on the quaranteed quality,with advanced technology and scientific management, our company develops with reputations for providing quality products and best service.



FAQ



Q:How to order the products?

You can send the inquiry with detail item description or with Model number. If possible please attach one

 reference pictureto avoid any misunderstanding or any links fromour website for we get a better

understanding.

PLs add the information in your inquiry.

1) the size of the tricone bit

2) the IADC tooth model, like 537G

3) PLs tell the drilling information of the layer.

4) PLs tell the quantity.

Q: Are you a manufacturer or trading company?
A: We are a specialized manufacturer.
Q: What are your main products, and used for?

A: Our products include core bit, PDC bit, reaming shell, core barrel, casing, drill rod, SPT equipment, Shelby sampler, drill rig and other drilling parts.They are used for mineral exploration, geological drilling, geotechnical engineering and soil sampling.

 Q: How about discount?
 A: Price is based on products and order quantity.
 Q: Do you accept sample order?
A: Yes sure, please contact us for details.
