Новый DJI MG-1plant аппарат для охраны сельскохозяйственных угодий культур распыления дрона с дистанционным управлением пустой виде объемлющей рамки из углеродистого волокна 10 кг

\tDJI MG-1 Octocopter Agricultural plant protection machine 2016 of the latest high precision spraying sure load 10 kg

Start selling, please contact customer service.

Open with new technology of agriculture in the future. DJI MG 1 designed for crop protection areas, integration of advanced flight control, reliable internal circulation cooling system, portable folding fuselage and manipulation of the simple custom remote control, provide you with efficient, safe and convenient plant protection tools.

Efficient operation

Equipped with strong eight shaft power system, big jiang standard load up to 10 MG - 1 kg. Production per hour can reach 40 to 60 mu, the efficiency is 40 to 60 times of artificial. The xinjiang pharmaceutical spray pump MG - 1 intelligent control with high precision, and speed linkage. In automatic operation mode, to achieve the constant speed, high flying and constant flow spraying, ensure the crops can be sprayed evenly, high efficient operation at the same time to save reagent, and prevent the soil from erosion of pollution.

AIRCRAFT FRAME
Diagonal Wheelbase
1520 mm
Frame Arm Length
625 mm
Dimensions
· 1471mm x 1471mm x 482mm (arm unfolded, without propellers)

· 780mm x 780mm x 482mm (arm folded)
PROPULSION SYSTEM
MOTOR
Stator Size
60mm x 10 mm
KV
130 rpm/V
Max Thrust
5.1 kg/rotor
Max Power
770 W
Weight (with cooling fan)
280 g
FOLDABLE PROPELLER
Material
High-performance engineered plastics
Diameter / Pitch
21x7.0 inch (533x178 mm)
Weight
58 g
ESC
Max Allowable Current (Continuous)
25 A
Operating Voltage
12S LiPo
Signal Frequency
30 to 450 Hz
Drive PWM Frequency
12 kHz
SPRAY SYSTEM
LIQUID TANK
Volume
\t10 L
Standard Operating Payload
10 kg
Max Battery Size
151mm x 195mm x 70mm
NOZZLE
Model
TXVK-04,XR11001
Quantity
4
Max Spray Speed
0.5 L/min (per nozzle, for water)
Spray Width
4 - 6 m (4 nozzles, 1.5 – 3 m above the crops)
Droplet Size*
· TXVK-04:80 ~190 μm

· XR11001:130 ~ 250 μm

*Droplet size may vary according to operation environment and spraying speed.

FLIGHT PARAMETERS

FEATURES

Total Weight (without batteries)
8.8 kg
Standard Takeoff Weight
22.5 kg
Max Takeoff Weight
24 kg (@ sea level)
Max Thrust-Weight Ratio
1.81 (with 22.5 kg takeoff weight)
Power Battery
2 x 6S LiPo (batteries of 12000 mAh, continuous discharging rate of 10C and charging rate of 1C to 2C recommended)
Max Power Consumption
6400 W
Hovering Power Consumption
3250 W (with 22.5 kg takeoff weight)
Hovering Time
· 24 min (@ 12000 mAh, with 12.5 kg takeoff weight)

· 10 min (@ 12000 mAh, with 22.5 kg takeoff weight)

Max Operating Speed
8 m/s
Max Flying Speed
22 m/s
Recommended Operating Temperature
0 to 40 centigrade
REMOTE CONTROLLER
FEATURES
Model
GL690B(Japan Only), GL658C
Operating Frequency
2.400 - 2.483 GHz

Max Transmission Range (unobstructed, free of interference)
· FCC: 5 km

· CE: 3.5 km
EIRP
100 mW @ 2.4 GHz
Built-in Battery
6000 mAh, 2S LiPo

Charging
DJI charger
Output Power
9 W
Operating Temperature Range
-10 to 40 centigrade
Storage Temperature Range
· Less than 3 months: -20 to 45 centigrade
· More than 3 months: 22 to 28 centigrade
Charge Temperature Range
0 to 40 centigrade
REMOTE CONTROLLER CHARGER
FEATURES
Model
A14-057N1A
Voltage
17.4 V
Rated Power
57 W

Does not include: battery, charger
