18650 li ion battery  Rechargeable Battery 18650 lipo battery





Item	Parameters		Remark
Rated Capacity	Typical	2200mAh	standard discharge(0.2C) after standard charge
	Minimum	2190mAh
Alternating  Internal Resistance	≤70mΩ
Nominal Voltage	3.7V		mean operation voltage
Voltage at end of Discharge	2.5V		discharge cut-off voltage
Charging at end of Voltage	4.20V
Standard Charge	Constant Current 0.2C Constant  Voltage 4.20V 0.02C cut-off		charge time:Approx 6.0h
Standard Discharge	Constant Current 0.2C end Voltage 3.0V
Fast Charge	Constant Current 1C Constant  Voltage 4.20V 0.02C5A cut-off		charge time:Approx 2.5h
Fast Discharge	Constant Current 1C end Voltage 3.0V
Cycle Characteristic	2000times(100%DOD) 4000 times(80%DOD) 7000 times(50%DOD)		the residual capacity is no less  than 80% of rated capacity at 1C rate.
Maximum Continuous  Discharge Current	2C		pulse discharge current: 5 C
Operation Temperature Range	Charge:0~55℃ Discharge:-20~60℃		60±25%R.H. bare battery
Storage Temperature Range	Less than 1 year:-20~25℃ Less than 3 months:-20~45℃		60±25%R.H. at the shipment







Precautions and Safety Instructions of Cylindrical Li-ion Battery

• Please pay attention to followings in case of batteries will have leakage, heat etc.


• Do not immerse the battery in water or seawater, and keep the battery in a cool dry surrounding if it stands by.


• Do not use or leave the battery at high temperature as fire or heater. Otherwise, it can overheat or fire or its performance will be degenerate and its service life will be decreased.


• Do not reverse the position and negative terminals.


• Do not connect the battery electrodes to an electrical outlet.


• Do not short circuit. Otherwise it will cause serious damage of the battery.


• Do not transport or store the battery together with metal objects such as hairpins, necklaces, etc.


• Do not strike, trample, throw, fall and shock the battery.


• Do not directly solder the battery and pierce the battery with a nail or other sharp objects.


• Do not use the battery in a location where static electricity and magnetic field is great, otherwise, the safety devices may be damaged, causing hidden trouble of safety.


• Use the battery charger specifically when recharging.


• If the battery leaks and the electrolyte gets into the eyes, do not rub the eyes, instead, rinse the eyes with clean water, and immediately seek medical attention. Otherwise, it may injure eyes.


• If the battery gives off strange odor, generates heat, becomes discolored or deformed, or in any way appears abnormal during use, recharging or storage, immediately stop charging, using, and remove it from the device.


• In case the battery terminals are dirty, clean the terminals with a dry cloth before use. Otherwise poor performance may occur due to the poor connection with the instrument.


• Tape the discarded battery terminals to insulate them.


• Uses the constant electric current and the constant voltage way charge, the prohibition reverse charges. If the battery positive electrode and the cathode meet instead, can damage the battery.


• Over-discharges: After the short time excessively discharges charges immediately cannot affect the use, but the long time excessively discharges can cause the battery the performance, battery function losing. The battery long-term has not used, has the possibility to be able to be at because of its automatic flashover characteristic certain excessively discharges the condition, for prevented excessively discharges the occurrence, the battery should maintain the certain electric quantity.


• Notice for Assembling Battery Pack: Shocks, high temperature, or contacts of sharp edge components should not be allowed in battery pack assembling process.



Storage of Cylindrical Li-ion Battery

• Batteries should be stored at room temperature (Temperature: 25±2℃;Humidity:(65±20% RH).


• Batteries are charged to about 30% to 50% of capacity.


• Batteries’storage voltage should be 3.3~3.4V .


• Batteries be charged about once per 3 months to prevent over discharge.





 We participate in a variety of trade fairs twice every year .On Electronics Show we discuss with customers

about our products and help them solve questions face to face.We have established contacts with many

potential buyers from other places as America, Australia, Belgium, Israel,Germany, the Netherlands,

Canada etc.
