3 лошади китайский лошадиный

Model\t3HALG-D

Materials\tChassis Material: double hot dip galvanized RHS (3.5mm-4.0mm)

\tFrame Material: double hot dip galvanized RHS (2.5mm)

\tBody Panel: galvanized sheet (1-1.5mm)

\tRoof: Special molded FRP 3mm

Brake\tPerfect security structure design, double axle electric brakes

Drawbar\tDrawbar Checker Plate 1.2mm aluminium

\tDrawbar Safety Chain two & Bracing Wheel one

Suspension\tRoll rocker tandem spring 9 plate

Axles\tTwo special trailer axles 50*50mm

Wheels & Tyre\tFive 195R15 tyres and 15'aluminum alloy rims, including a spare tire

Rubber Matting\t18mm special plywood for floor& ramp door

\tRubber Matting For Inner Side Panel 6mm Rubber Matting

\tRubber Matting For Floor & Ramp Door 17.5 mm anti-slip rubber sheet

Window &Door\tSide Windows 3 drop-down windows,4 caravan windows,2 rectangular windows

\tSkylights three large size upturning ventilation windows

\tRear Upper Door (mm) 1980*1065 Strut & High-intensity anti-rust strut

\tRamp Door (mm) 2030*1210

\tSide Door (mm) 1730*630 caravan door

\tHinges for Rear Upper Door special 6mm diameter copper hinges

Supporting Wheel\tSwing-able knight supporting wheels to make parking safe and reliable

Lights& Petro Reflectors\tTrailer Plug Seven-prongs Plug

\tRear Lights brackets aluminium

\tLED interior lights, two small LED sidelights, two LED combination taillights

\tRetro Reflectors 12

Auxiliary Fittings\tHorse Protection Frame fully padded

\tHorse Ring six

\tSaddle Rack in saddle box for 3 horses

\tRug Rack side

\tSaddle Box one

\tWater Tank one

\tPump one

\tAwning one

Human room\tCupboard side

\tSink one

\t

\t

\t

\t

Dimensions\tOverall Dimension (L x W x H: mm): 8600x 2280 x 2590

\tBody Dimension (L x W x H: mm): 7750 x 1930 x 2155

\tInner Dimension(L x W x H: mm): 7725 x 1930 x 2155

\tLength of Tone (mm):2300

Empty Weight\t2400 KG

Carrying Capacity\t3000 KG
