Roller ground paver frame concrete floor leveling paver concrete pavement leveler

HZP spiral concrete paver machine in accordance with international standards for the design and production, this paver with paving, Ment pulp, vibrating,  leveling and other functions.

The largest advantage is to resolve general paver leveling machine working problems in restricted construction sites. Since its rollers can be easily changed and easy to transport.

Concrete paver leveling machine can be widely used in a variety of highway, municipal roads, squares, airport runways and other concrete construction. It is also very suitable for concrete pavement, concrete surface layer of the tunnel, bridges and paving construction.

Features:

1.ZB series vibrator is used to implement vibration and lifting, the vibration frequency is high and the compacting effect is good.

2.Paving institutions can achieve a balanced paving of concrete materials, saving manpower, paving high efficiency.

3.Efficient vibrating mechanism allows the concrete to flow, thus effectively ensuring the density of the concrete, especially for low-slump concrete, but also to achieve the desired density and leveling effect.

4.Using a unique steering mechanism to correct, you can easily achieve the driving direction and template to maintain parallel.

5.Reasonable driving from the total body design, making it easy to operate, comfortable, easy and comfortable.

One axis of HZP219 is responsible for walking, one axis is in charge of leveling, another one is in charge of lifting the pulp (four axes). Besides the above three axes, in the front part of the lifting shaft is added a helical shaft, Play the role of screeding and reduce the burden after a few shafts, the paving effect is more obvious.

Model	Two axles concrete paver machine	Three axies concrete paver machine
Paving thickness	200-300mm	200-300mm
Voltage	380v	380v
Rated power	4.5KW	10.5KW
Roller shaft diameter	219mm	219mm
Paving width	3500-5500mm	3500-5500mm
Walking speed	4.7m/min	4.7m/min
Dimension	L X 850X630mm	L X 1550 X 1350mm
Weight	600kg	800kg
Excitation force	4.2kwn/5.5kwn	4.2kwn/5.5kwn
