Жидкого азота расходомер для сжиженного нефтяного газа по
- Категория: Flow Meters >>>
- Поставщик: Shanghai,Cowell,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 1190.44 $* | 1250.71 $* |
| Aug-19-2025 | 1180.66 $* | 1239.68 $* |
| Jul-19-2025 | 990.61 $* | 1040.78 $* |
| Jun-19-2025 | 1160.73 $* | 1218.64 $* |
| May-19-2025 | 1010.95 $* | 1061.8 $* |
| Apr-19-2025 | 1140.35 $* | 1197.39 $* |
| Mar-19-2025 | 1130.76 $* | 1187.23 $* |
| Feb-19-2025 | 1120.7 $* | 1176.14 $* |
| Jan-19-2025 | 1110.52 $* | 1166.74 $* |
Характеристики
3inch positive displacement diesel mechanical digital flow meter LC flowmeter | |
M-50-kx-1 Meter with Register | Characteristics• Excellent stepless adjusting mechanism allows a micro adjustment of the meter • High accuracy and repeatability over the widest range of flow; Superior accuracy at constant flow • Low maintenance, no metal-to-metal contact in measuring chamber, long life service • Low pressure loss, a true gravity flow meter • Accuracy regardless of pressure fluctuations, temperature variation, viscosity • Choice of aluminum, cast iron and stainless steel materials of construction |
Construction | |
Technical Specification | |||||||||
Model | M-40-1 | M-50-1 | M-50H-1 | M-80-1 | M-80H-1 | M-100-1 | M-100H-1 | M-150-1 | M-150H-1 |
Size | 40mm /1.5” | 50mm / 2 " | 80mm / 3 " | 100mm / 4 " | 150mm / 6 " | ||||
Flow Range | 25-250 | 38-380 | 55-550 | 75-750 | 115-1150 | 130-1300 | 170-1700 | 225-2250 | 300-3000 |
Volume/Rev. | 0.309L | 0.681L | 1.839L | 5.102L | 9.507L | ||||
Max.Pressure | 10Bar/150PSI | 25Bar/350PSI | |||||||
Accuracy | ±0.2% | ||||||||
Repeatability | ≤0.05% | ||||||||
Standard Measurement | Liter / US Gallon/IMP Gallon | ||||||||
Viscosity | 30SSU~1,500,000SSU | ||||||||
Note:4"&6" flange available for M-150/6" Meter.
Packaging Data | |||||
Model | M-40-1 | M-50-1 | M-80-1 | M-100-1 | M-150-1 |
Packaging | 1 pc/Wooden Case | ||||
Net Weight | 23Kgs | 26Kgs | 40Kgs | 70Kgs | 130Kgs |
Gross Weight | 35Kgs | 38Kgs | 55Kgs | 90Kgs | 155Kgs |
Size | 53×48×53cm | 53×48×53cm | 58×50×61cm | 76×64×72cm | 80×65×79cm |
Industries• Automotive; • Adhesives; • Agriculture; • Asphalt ; • Aviation fueling ; • Animal feeds; Beverage; • Cosmetics ; • Chemical processing; • Concrete Add mixtures; • Dairy; Liquid fertilizers; • Food processing ; • Fuel oil delivery; • General industrial; • Hydrocarbon processing; • Liquefied gases; • Lube oils; Marine; • Paint and varnish; • Petroleum marketing; • Petroleum production ; • Pharmaceutical; • Printing ink; • Pulp &paper; • Refining commercial Solvents; • Recycling Railroad ; • Textile. | Application• Refined petroleum products; • Aviation gasolines and jet fuels; • A wide variety of products such as: liquid sugars, corn syrup, corn sweetners, dextrose,fructose, sucrose, maltose, lactose, corn oil, soy bean oil, cotton seed oil, coconut oil; • Treated waters (deionized, demineralized, and potable); • Chlorinated solvents and general solvent metering; • Acid pH liquids; • Liquefied petroleum gas(LPG); • Crude oil, also for heated and/or viscous liquids; • Oil or water based latex products, polyester resins, and adhesives (neutral pH), also for metering herbicides and nitrogen fertilizer solutions; • Herbicide; • Sodium hydroxide (caustic) solutions, high sulfur crude oil (LACT and NOD) and other alkaline pH liquids; • Abrasive liquids. |
M-80-1 Meter |
M-80-1 Meter with Counter |
M-80-1 Meter with Counter & Strainer |
M-80-1 Meter with Counter, |
M-150-A-1 Meter with Counter |
M-50-KX-1 Meter with Register Counter, |
M-80-G-1 Meter with Counter,Strainer, |
M-50-NX-1 Meter with Preset Counter, |
M-80-KPX-1 Meter with Electronic Register, |
M-50-PP-1 Meter with Pulser |
MA-40-CX-10 LPG Dispenser Meter with Two Meters, |
MA-50-CX-10 Meter with Register Counter |
FAQ
How to contact us?
Please add our webchat:y303154623y
online chat skype:yanchen287
whatsapp:86 18521702173
