Соединительная рама экскаватора для литья железной дороги запасные части от китайского

Material

Carbon steel, alloy steel, stainless steel,Aluminum alloy, Copper, ect.

Process

Lost wax casting + cnc machining

Casting dimension tolerance

CT7

Casting surface roughness

Ra 12.5 um

Casting weight range

0.1-90 kg

Casting Size

Max linear size: 1200 mm, Max diameter size: 600 mm

Machining Precision

Positioning accuracy 0.008 mm, Rep. position. accuracy 0.006 mm

Machining surface roughness

Ra0.8 ~ 6.3 um

Max Travel Of Spindle

1900 mm x 850 mm x 700 mm

Max Turning Diameter

830 mm

Material standard

GB, ASTM, AISI, DIN, BS, JIS, NF, AS, AAR

Surface treatment

KTL (E-coating), Zinc plating, Mirror Polishing, Sand Blasting, Acid pickling, b-lack oxide, Painting, Hot galvanizing,Powder coating, Nickel plating.

Service available

OEM & ODM

Quality control

0 defects,100% inspection before packing

Application

Train & railway, automobile& truck, construction machinery, forklift, agricultural machinery, shipbuilding, petroleum machinery,
construction, valve and pumps, electric machine, hardware, power equipment and so on.

Keywords

Investment casting, steel casting, precision casting, lost wax casting
