CATV Цифровой головной узел OPT прибора D600 24 канал Cvbs Устройство цифрового телевидения h.264 SD
- Категория: Радио и ТВ аксессуары >>>
- Поставщик: Hangzhou,Runzhou,Fiber,Technologies,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.81 $* | 0.33 $* |
| Aug-16-2025 | 0.46 $* | 0.66 $* |
| Jul-16-2025 | 0.35 $* | 0.12 $* |
| Jun-16-2025 | 0.78 $* | 0.29 $* |
| May-16-2025 | 0.74 $* | 0.33 $* |
| Apr-16-2025 | 0.59 $* | 0.53 $* |
| Mar-16-2025 | 0.3 $* | 0.50 $* |
| Feb-16-2025 | 0.70 $* | 0.11 $* |
| Jan-16-2025 | 0.62 $* | 0.70 $* |
Характеристики
Product Description
1. Description:
OPT D600 24 in 1 MPEG-2 Encoder (with IP output) is a professional audio&video encoding and multiplexing device. This device has 24 CVBS input interfaces and 24 pairs of unbalanced analogue stereo audio input interfaces, and 1 ASI output interfaces which can output the multiplexing and condensed data. Moreover, this device can simultaneously encode 24 channel audio& video signal and can multiplex stream through ASI and IP port. Besides, it supports the criterion MPEG-2 encoding format, and the audio encoding formats supports MPEG1 Layer2, MPEG2-AAC and MPEG4-AAC. Furthermore, this encoder has the IP output function; users can manage the device according to the Web. In conclusion, its high compatibility and integrate design make this device widely used in a variety of digital TV broadcasting systems.
2. Key features:
1. Supports MPEG-2 video encoding
2. Support MPEG-1 Layer2, MPEG2-AAC and MPEG4-AAC audio encoding.
3. 24 CVBS video input
4. 24 pairs of unbalance stereo audio input
5. Supports PAL, NTSC SD signal
6. Support ASI out put (as copy of MPTS2)
7. Supports 8 MPTS (UDP, RTSP) and 512 SPTS (UDP, RTSP/ RTP) output (unicast/multicast)
8. Support web management
4. Technical paramater:
Input | 24 CVBS inputs , BNC interface 24 pairs unbalanced stereo audio input, BNC interface | |
Video
| Resolution
| 720×480_60i, 544×480_60i, 352×480_60i 352×240_60i, 320×240_60i, 176×240_60i, 176×120_60i |
720×576_50i, 704×576_50i, 640×576_50i, 352×288_50i 320×288_50i, 176×288_50i, 176×144_50i, | ||
Encoding | MPEG-2 | |
Bit-rate | 0.1Mbps~8Mbps each channel | |
Rate Control | CBR/VBR | |
GOP Structure | IBBPB | |
Advanced Pretreatment | De-interlacing, noise reduction | |
Audio
| Encoding | MPEG-1 Layer 2, AC3 |
Sampling rate | 48KHz | |
Resolution | 24-bit | |
Bit-rate | 128Kbps,192kbps,256kbps,320kbps,384kbps each channel | |
Multiplexing | Multiplex with local 24 channels TS | |
Stream output
| 1-way ASI output, BNC interface | |
512 SPTS (UDP, RTSP/RTP) output from GE1, 8 MPTS (UDP,RTP) output from GE2, Unicast/Multicast, RJ45/SFP interface | ||
System function
| LCD/keyboard, network management(WEB) Chinese and English language | |
Ethernet software upgrade | ||
Miscellaneos
| Dimension(W×L×H) | 482mm×410mm×44mm |
Approx weight | 8kg | |
Environment | 0~45℃(work);-20~80℃(Storage) | |
Power requirements | AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz | |
Power consumption | 20W | |
Packaging & Shipping
Our Services
Our advantage:
1. Competitive price
2. Fast delivery
3. Free sample provided
4. Long time warranty
5. Reliable quality, OEM service available
6. Professional product and technical support
7. Prompt answer for any question or inquiry
