Акриловое/акриловое окно для бассейна с высокой твердостью
- Категория: Other Pool & Accessories >>>
- Поставщик: Guangzhou,Grandview,Material,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 209.86 $* | 219.98 $* |
| Aug-20-2025 | 208.29 $* | 218.85 $* |
| Jul-20-2025 | 174.76 $* | 183.56 $* |
| Jun-20-2025 | 204.65 $* | 214.57 $* |
| May-20-2025 | 178.29 $* | 187.69 $* |
| Apr-20-2025 | 201.94 $* | 211.88 $* |
| Mar-20-2025 | 199.99 $* | 209.27 $* |
| Feb-20-2025 | 197.68 $* | 207.64 $* |
| Jan-20-2025 | 195.69 $* | 205.32 $* |
Характеристики
Products and Applications
Why Choose Us
Strong Production Capacity
7-10 days short production time, huge stock, large capacity.
QC
Examine the interior of each Acrylic Panel under light
Flat surface
Milling surface smooth on each panel
Tempered
Remove internal stress Tempered in Oven each panel
Top Edge Polishing and Chamfering
The top edge is polished and chamfered to protect the body from scratches
Blue Painting if necessary
Decorate the installation sides with green blue paint.
45 or 90 degrees Bonding
Superb bonding technology, so that the seams perfect
SGS Test
Test tensile strength and vicat softening temperature for each production batch.
3D design
1.Offer on site installation service and technical support
2.We serve customer with customized acrylic and turnkey project. In a word just tell us your dimension or suggestion; We will try.Our best to satisfy you. You can rest assured that both our quality and service are the best.
How to order
1.TELL US THE SIZE
Tell us your swimming pool length,width and height,water level.It is better have design file.
2.DRAFT DESIGN
By finite element analysis,we sure the thickness of acrylic,we draw design for you.
3.PRODUCTION
We start production,cutting,bonding,bending,polishing,QC and packing,shipping to you
4.INSTALLATION
We provide you installation guide,our engineer can go to your side to do installation if necessary
Products Description
Material | Lucite Acrylic |
Thickness | 20-300mm customized |
Color | Clear/transparent |
Shape | Customer's Demand |
Surface | High Surface Hardness |
Light transmission | High light transmission(95%) |
Diaphaneity | More than 93% |
Packing | PE film masking on both sides,KT board and angle iron. |
Application | undersea world, Oceanarium, Zoo, Luxurious hotels, Swimming pools and so on. |
Data sheet
PROPERTIES | VALUES | RULES |
Density | 1.19 g/cm3 | ISO 1183-1:2012 Method A |
Rockwell Hardness | 112L | ISO 2039-2:1999 |
Tensile Modulus | 3150MPa | EN ISO 527:2012 |
Tensile Strength | 80.0MPa | EN ISO 527:2012 |
Tensile Strain at Break | 3.2% | EN ISO 527-1:2012 |
Water Absorption | 0.20% | ISO 62:2008 Method 1 |
Total Luminous Transmittance | 93.4% | ISO 13468-1:1996 |
Vicat Softening Temperature | 105℃ | ISO 306:2013 Method B50 |
Light Ageing Test- UV Exposure | Grey scale: 5 | ISO 4892-3:2016 Cycle 1 |
Mean Coefficient of Linear Thermal Expansion | 72×10-6 K-1 | ISO 11359-1:2014 |
Compressive Stress at Yield | 129MPa | EN ISO 604:2003 |
Flexural Strength | 120MPa | ISO 178:2013 |
Compressive Yield Strength | 111MPa | ASTM D695-15 |
Compressive Modulus | 3450MPa | ASTM D695-15 |
Shear Strength | 59.7MPa | ASTM D732-17 |
Deflection Temperature under Load | 100.2℃ | ASTM D648-18 Method B |
Modulus Elasticity | 2810MPa | ASTM D695-15 |
Case studies and reviews
Product is as advertised, great communication with company representative.
Good quality and repurchase many times
I recommend this supplier for customised acrylic panels for underwater windows. Their sales representative; Ms.Karen Chen has been very helpful. She even arranged for the refund to us when eventually we reduced the size of our acrylic panel.
The swimming pool wall have nice quality, thank you Niki, you are professional, I will introduce a neighbor to you, he also like it.
Packaging and shipping
Certifications and company
