Подходит для черчения ковша экскаватора PC60 PC100 PC120 PC130 PC200 PC220 PC240 PC270 PC300 PC400 PC450

Описание и отзывы

Трекер стоимости

Характеристики

 1.Production description



Machine Model	All the famous brand
Type	Stardard/heavy duty/rock
Material	Q345B/NM360/HARDOX500
Capacity	0.1-12m3
Weight	200-12000kgs
Colour	customized
environment	Rock,clay,sand,soil,gravel



We can design and manufacture various bucket for any brand, even can scientifically solve the problem of stress according to the difference working enviroment or requirements from customers, choose the selected material, and finish the design by CAD, also obtain the integrated quality controlling procedure for welding, so that the hardness of the structure, using capability and quality can be ensured.

Suitable machinery: From 1 T to 120 T , for Caterpillar, Kobelco, Hitachi, Hyundai, for Komatsu, JCB and other brand. The specification covers from 0.1m3 to 12m3 and so on.





2.Bucket material



The chemical ingredients and Mechanical Performance comparison of three materials:KM
Materials\\Items	Code Name	The main chemical components					(HB) Brunel Hardness	Elongation Rate(%)	(N/mm2) Tensile Strength	(N/mm2) Yield strength
		C	Si	Mn	P	S
Manganese Steel plate	Q345B	0.18	0.55	1.4	0.03	0.03	360	16	1200	1020
Wear-resistant steel plate  homemade	NM360	0.2	0.3	1.3	0.02	0.006	163-187	21	470-660	345
High strength   wear-resistant steel plate	HARDOX500	0.2	0.7	1.7	0.025	0.01	470-500	8	1550	1300





3.Bucket capacity

R485 R485LC-9T excavator bucket



Bucket capacity	Excavators
0.1-0.3m3	equipped for 5-6±tons
0.5-0.6m3	equipped for 14±tons  excavators
0.9-1.1m3	equipped for 21±tons excavators
1.1-1.2m3	equipped for 24±tons excavators
1.2-1.4m3	equipped for 29±tons excavators
1.7-1.9m3	equipped for 36±tons excavators
2.1-2.6m3	equipped for 46±tons excavators
