HUALI лидер продаж компьютер 5 цветов печатная машина/флексографские чернила для гофрированного картона высекальная машина высокого

HUALI лидер продаж компьютер 5 цветов печатная машина/флексографские чернила для гофрированного картона высекальная машина высокого

Категория: >>>
Поставщик: Dongguang,County,Huali,Carton,Machinery,Factory

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.53 $*	0.43 $*
Aug-16-2025	0.99 $*	0.63 $*
Jul-16-2025	0.12 $*	0.10 $*
Jun-16-2025	0.82 $*	0.59 $*
May-16-2025	0.37 $*	0.48 $*
Apr-16-2025	0.56 $*	0.78 $*
Mar-16-2025	0.57 $*	0.17 $*
Feb-16-2025	0.34 $*	0.55 $*
Jan-16-2025	0.27 $*	0.0 $*

Характеристики

Product Description

HUALI small corrugated board box 2 colors flexo printing making machine

1	Color group	to be configured according to user's needs
2	Printing paper	A,B,C,A/B,B/C and A/B/C type corrugated paperboard (the maximum interval 11mm)
3	Width of machine inside	2200mm	2600mm	2800mm
4	Max.paper size	900×2000mm	1200×2400mm	1400 ×2600mm
5	Max.printing size	900×1800mm	1200×2200mm	1400 ×2400mm
6	Skip feeding paper	1100×2000mm	1400×2400mm	1600 ×2600mm
7	positive knife Min.paper size negative knife	300×640mm 300×720mm	350×720mm 350×740mm	400 ×720mm 400 ×740mm
8	Printing plate thickness	7.2mm	7.2mm	7.2mm
9	Design speed(piece/min)	200pcs/min	180pcs/min	150pcs/min
10	Economic speed(piece/min)	80-180pcs/min	80-160pcs/min	80-130pcs/min
11	Tinted precision	4( color) ±0.5mm	4( color) ±0.5mm	4( color) ±0.5mm
12	Slotting precision	±1.5mm	±1.5mm	±1.5mm
13	Max.slotting depth	7 ×220mm	7×300mm	7×350mm
13	Max.slotting depth	increase the blade, increase the slot depth
14	positive knife Min. Slot distance negative knife	150 ×150 ×150 ×150mm 250 ×90 ×250 ×90mm	170×170×170×170mm 260×90×269×90mm	260×90×269×90mm 260×90×269×90mm
15	Max.die-cutting size	260×90×269×90mm	260×90×269×90mm	260×90×269×90mm
16	Printing plate diameter (contain plate thickness)	260×90×269×90mm	260×90×269×90mm	260×90×269×90mm

Function and characteristic

1The whole machine is adopted international famous brand appliances and computer software,the quality is stable and reliable .Man-machine interface, Multi-point touch screen control ,computer order management, easy to operate.Replace the order faster(can be stored 999 orders in advance)

2Whole wallboard and important components are adopted aging treatment, eliminate the metal internal stress;Adopt high precision machining centers, CNC grinding machine for grinding processing.

3The machine shaft, roller are adopted high quality steel, grinding processing, high precision computer dynamic balancing correction and surface hard chromium plating.

4The engine drive gear is adopted 20CrMnTi alloy steel, carburizing,quenching treatment, hardness HRC58-62 and gear grinding processing precision level 6, and ensured the long-term use of tinted with high precision

5Machine transmission parts (shaft, gear joint) are adopted free key connection (LOCK-ALX), the connection eliminate clearance. It is suitable for long-term high speed with high torque.

6The machine drive bearing ,important driving parts adopt Heavy-duty self-aligning bearing ,simple maintenance,long service life. (three big domestic famous brand:Hava los)

7The engine lubrication system is adopted automatic spray type lubrication, Equipped with automatic balancing device, keep the oil in every units at the same level.

8The machine is adopted adjustment preset functions, feeding , printing, slotting, die-cutting, automatic zero resetting ,Separate and combine memory automatic reset.

9It adopts Working gap adjustment, rapid adjustment without wrench, quick performance and convenient adjustment..

10The main motor is adopted frequency conversion control.It makes start, running more steadily and saves more energy.

11There is lack of ink alarm device and the real-time monitoring for the ink working condition system .

12Optional: ceramic anilox roller, doctor blade and set ink system, stacking machine.

Our Services

12 months warranty

24 hours online service

Providing free quick-wear parts

Engineers available to service overseas if necessary

Product certificated by CE and so on

And Cooperation company

Customer visit

At present, our factory with South Korea, the United States, Spain, Australia, Poland, Turkey, Canada, Lithuania, Indonesia, Mexico, Saudi Arabia, Egypt and so on more than 60 countries have a business relationship and cooperate happily for a long time, many countries have my company agents.
