used engine oil into diesel oil Distillation Systemcycling equipmentm



 Product introduction

It is suitable for purification recycling of all sorts of waste oil treatment machine researched by our company through many times of experiment combined with the actual situation. It can effectively remove the tiny particles and Colloidal matter in the waste oil, plastic tyre oil, and meanwhile it can remove the odour of the oil, and finally makes the oil color looks clean and transparent and improve the economic value. It features high recycling rate, low costs of energe consumption, good oil processing ability. All of our machines are designed and produced by ourselves, we are not third-party! we have our own trade mark right, export license, patents etc. And We have all rights about all our product pictures and technolgy!



 Parameters:

Parameters	DIR-1	DIR-2	DIR-3	DIR-4	DIR-5	DIR-6	DIR-7	DIR-8
Capacity	1T/D	2T/D	3T/D	4T/D	5T/D	6T/D	8T/D	10T/D
Total Power	49KW	59KW	69KW	78KW	82KS	90KW	110KW	120KW
Rated Power	68KW	80KW	100KW	110KW	125KW	140KW	150KW	165KW
Vacuum Degree	-50Pa
Heating Method	gas/electric
Oil Heating Temp	180℃-270℃
Voltage	220V/380V/415V
Noise	≤60dB
Dimension	7*6*7.5M	8.5*6.5*7.5M	9*7*7.5M	9.5*7.5*7.5M	10*8*7.5M	11*8.5*7.5M	13*9*7.5*	15*10*7.5M



Main Features

1) Adopting qualified steel with 20mm thickness tank, seamless welding, much stronger to keep safty!
2) The recovery rate: used tire(raw material)40~50%, waste oil&pyrolysis oil(raw material)≥90% ,plastic(raw material)20%~75%.
3) Europe III emission standard, the exhaust gas can be reached the environmental protection in Singapore! Plz check the exhaust test reports!
4) Engineers available to go abroad for FREE installing, commissioning machinery, training for machines installation and operation of the staffs!



Environmental protection

Through two safety devices,water seal and gas nozzle,not only eliminate air pollution but also save amount offuel.Soot emission can be reached the standard of Emission standard of air pollutants for coal-burning oil-burning gas-fired boiler GB13271—2001.



After-sales services

One year guarantee for product quality. (People damaged parts are charged).
Lifelong maintenance and spare parts supply.
Free design of fixtures as customers required.
Free training for machines installation and operation of the staffs



Technological process

Technological process: pump the waste oil into the negative pressure thermal cracking pyrolysis ffurnace, heat it and distillate into oil vapour, the oil vapour pass through the gas manifold,then go throught three-stage condenser to cool down the hot vapor to pethol and diesel oil;the waste gas will be collect and transport to the burner as fuel; and the residuel will be discharged automatically by sprial.



Applicable scope

1. waste plastics, crude oil, waste rubber, used tyres...
2. waste oil. For example: waste gasoline diesel oil, waste oil, waste engine oil, waste oil sludge, waste crude oil, waste oil used to wash spare parts, and so on.
3. various kinds of waste animal oil, vegetable oil, acidated oil, heavy oil, waste lube oil, alcohols, sulfonated oil, naphtha, paraffin, benzene, naphthalene, ketones).

Her are our main categories below:

ZJB Single stage vacuum transformer oil purifier
 ZJA Double stage vacuum transformer/insulating oil purifier
ZJA-M Mobile Trailer type transformer oil purifier
IIJ-II Insulating/transformer oil dielectric strength tester
ZJD Lubricant/hydraulic/turbine oil purifier

ZJF  Cooking oil purifier
NRY Waste engine oil regeneration system
ZJD Coalescence and separating oil purifier
ZJR Phosphate ester fire-resistant oil purifier
ZJD-K Plate pressure oil purifier, Portable oil purifier
AD Air dryer for drying electric equipments
ZJD-S Oil water separator

DIR Waste engine oil distillation plant

DDR Diesel oil distillation plant

NKEE-36 Oil moisture sensor

BDV Oil tester

Contact Anna Wu for more details. whatsapp/wechat/mobile:008615215080377
