Солнечная поддержка промышленный генератор воздушной воды чистая вода от air

Описание и отзывы

Трекер стоимости

Характеристики

solar support Industrial air water generator pure water from air 500L

Founded in 2002 in Hangzhou, AQUAOSMO has designed and manufactured innovative water drinking solutions for home,office and commercial environments.We focus on providing clean,healthy and safe drinking water in a new ,sustainable eco-friendly way with good quality for municipal and government buildings and schools ,hospitals ,airport and residential home.



In year 2015,we have set up a auto assembly line for household appliances. Our daily output can reach 2000sets with good quality level.

The large capacity air water generator is especially suitable for the following areas:Small towns,disasters area,flood locations


Large Capacity air water generator captures the moisture from outsid air and turns it into the purest,healthest and highly axygenated drinking water avialable on earth.In the process of remove moisture from outside air,the air is dehumidified and cooled making it ideal air to add into indoor environments.The aquair system serves several purposes;making water ,dehumidiying the air,conditioning outside air and effectively purifying indoor air.All are accoplished with a single source of enegry thereby making the large capacity system a unique energy efficient water making system available today.

Model		BWT-A100	BWT-A250	BWT-A500	BWT-A1000	BWT-A2000	BWT-A3000	BWT-A5000	BWT-A10000
Power Supply		220~230V 50Hz, single-phase voltage	380V 50Hz three-phase voltage
Power Rating (KW)		1.2 KW	3 KW	5.5 KW	9.2 KW	18.5 KW	27.5 KW	46 KW	92 KW
Water Production (Liters/Day) @ 27°C & RH-80%		100L/24Hr (@ 30°C & RH-80% )	250L/24Hr (@ 30°C & RH-80% )	500L/24 Hr (@ 27°C & RH-80% )	1000L/24Hr (@ 27°C & RH-80%)	2000L/24Hr (@ 27°C & RH-80% )	3000L/24Hr (@ 27°C & RH-80% )	5000L/24Hr (@ 27°C & RH-80% )	10000L/24Hr (@ 27°C & RH-80% )
Compressor Power		1x 0.85kw	1x 1.8kw	1x 3kw	2x 3kw	2x 6kw	3x 6kw	5x 6kw	10x 6kw
Machine Dimension (LxWxH) cm		100x55x100	195x91x177	220x65x207	220x130x201	220x185x207	220x330x207	220x550x207	220x1010x199
Net Weight (kg)		185	300	400	850	1700	2600	4500	9200
Operational sound level (dB)		≤50Db	≤55Db	≤65Db	≤70Db	≤70Db	≤70Db	≤70Db	≤70Db
Water Tank		40L	Upper 45L+ Bottom47 L	Upper 87L + Bottom 65L	Upper 180L+ Bottom 109 L	Upeer 180L+ Bottom 180 L	200L	300L	700L
Air fiter dimension (cm)		1#: 45*49*36 x1se	1#: 45*49*36 x1se	1#: 45*49*36 x1set 2#: 45*49*60 x1set	1#: 45*114*36 x1set 2#: 45*114*60 x1set	1#: 45*169*36 x1set 2#: 45*169*60 x1set	1#: 45*150*36 x2set 2#: 45*150*60 x2set	1#: 45*220*36 x2set 2#: 45*220*60 x2set	1#: 45*220*36 x4set 2#: 45*220*60 x4set
Working condition	Temperature	Standard working temperature:     20°C - 38°C In case the temp below 20°C or higher 38°C, System needs to be customized
	RH	35% - 95%
Compressor Brand		SUMSUNG or Panasonnic	EMERSON	EMERSON	EMERSON	EMERSON	EMERSON	EMERSON	EMERSON
Refrigerant		R407	R407	R407	R407	R407	R407	R407	R407
Phase Protection of Compressor		1.Delay Protection            2.Hi & Low  Pressure Protection 3. Overheat & Overload Protection	- Phase-sequence Protection  - Delay Protection  - Hi & Low  Pressure Protection  - Overheat & Overload Protection
Defrost Method		FAN COOLING	FAN COOLING	FAN COOLING	FAN COOLING	FAN COOLING	FAN COOLING	FAN COOLING	FAN COOLING
Control system		SPC	SPC	SPC	SPC	SPC	SPC	SPC	SPC
Filteration system (Qty -Nos.) 7 stage filters	PPF	1	1	1	1	1	1	1	1
	CTO	1	1	1	1	1	1	1	1
	UDT	1	1	1	1	1	1	1	1
	UF	1	1	1	1	1	1	1	1
	UV	1	1	1	1	1	1	1	1
	Mineralization	1	1	1	1	1	1	1	1





The water output from 100L to 20000L one day are available.Please contact us for details.Thanks.
