High Quality Multilayers Rigid PCB Circuit Board Manufacturer In
- Категория: Жесткая печатная плата >>>
- Поставщик: Shenzhen,Wonderful,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.44 $* | 0.63 $* |
| Aug-17-2025 | 0.82 $* | 0.91 $* |
| Jul-17-2025 | 0.65 $* | 0.76 $* |
| Jun-17-2025 | 0.34 $* | 0.91 $* |
| May-17-2025 | 0.74 $* | 0.64 $* |
| Apr-17-2025 | 0.88 $* | 0.67 $* |
| Mar-17-2025 | 0.22 $* | 0.56 $* |
| Feb-17-2025 | 0.34 $* | 0.79 $* |
| Jan-17-2025 | 0.28 $* | 0.7 $* |
Характеристики
If desired, we will source, organise and manage all aspects of the PCB design, so that your product meets all required standards and is fully optimised for easy and cost effective manufacturing.
A well designed circuit board means:
· A reduction in production problems
· Improved quality control
· Reduced costs
· Reduced manufacturing times
We work to supply small and large batches of competitively priced printed circuit boards to our customers.
PCB&PCBA Capabilitise
PCB Capability | ||||||||
Number of Layer | 1 - 20 Layer | |||||||
Maximum Processing Area | 680 × 1000MM | |||||||
Min Board Thickness | 2 Layer - 0.3MM ( 12 mil ) | |||||||
4 Layer - 0.4MM ( 16 mil ) | ||||||||
6 Layer - 0.8MM ( 32 mil ) | ||||||||
8 Layer - 1.0MM ( 40 mil) | ||||||||
10 Layer - 1.1MM ( 44 mil ) | ||||||||
12 Layer - 1.3MM ( 52 mil ) | ||||||||
14 Layer - 1.5MM ( 59 mil ) | ||||||||
16 Layer - 1.6MM ( 63 mil ) | ||||||||
18 Layer - 1.8MM ( 71 mil ) | ||||||||
Finished Board Thickness Tolerance | Thickness ≤ 1.0MM, Tolerance: ± 0.1MM | |||||||
1.0MM ≤ Thickness ≤ 6.5MM, Tolerance ± 10% | ||||||||
Twisting and Bending | ≤ 0.75%, Min: 0.5% | |||||||
Range of TG | 130 - 215 ℃ | |||||||
Impedance Tolerance | ± 10%, Min: ± 5% | |||||||
Hi-Pot Test | Max: 4000V/10MA/60S | |||||||
Surface Treatment | HASL, With Lead, HASL Free Lead | |||||||
Flash Gold, Immersion Gold | ||||||||
Immersion Silver, Immersion Tin | ||||||||
Gold Finger, OSP | ||||||||
PCB Assembly Capability | PCB Assembly Capability | |||||||
Order Quantity | 1pc – 10,000,000+pcs | |||||||
Build Time | 1 – 5 days, 1 – 2 weeks, or scheduled deliveries | |||||||
PCB Spec Requirements | PCB whose width/length is less than 30mm should be panelized Max board size: 500×450 mm Board Type: Rigid PCBs, Flexible PCBs, Metal core PCBs Surface finish: lead/lead-free HASL, ENIG, Silver, OSP | |||||||
Assembly Types | Surface mount Thro-hole Mixed technology (SMT & Thru-hole) Single or double sided placement Conformal coating Shield cover assembly for EMI emission control | |||||||
Solder Type | Lead-free – RoHS | |||||||
Parts Procurement | Full Turnkey Partial Turnkey Kitted/Consigned | |||||||
Component types | SMT 01005 or larger BGA 0.4mm pitch, POP (Package on Package) WLCSP 0.35mm pitch Hard metric connectors Cable & wire | |||||||
SMT Parts Presentation | Bulk Cut tape Partial reel Reel Tube Tray | |||||||
Stencils | Laser-cut stainless steel | |||||||
Other Techniques | Free DFM Review Box Build Assembly 100% AOI test and X-ray test for BGA IC programming Components cost-down Function test as custom Protection technology | |||||||
It can be a challenge to find the optimal supplier for PCBs – meeting each and all customers’ expectations and requirements on price, quality, lead times, value-added services, and delivery. Wonderful PCBs is confidant that we meet each and every expectations for your each PCB.
