Мультимедийный промышленный фильтр для воды/кварцевый песок/фильтры с активированным углем очистки

Мультимедийный промышленный фильтр для воды/кварцевый песок/фильтры с активированным углем очистки

Категория: Water Filter >>>
Поставщик: Jiangsu,YLD,Water,Processing,Equipment,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	0.82 $*	0.38 $*
Aug-18-2025	0.62 $*	0.84 $*
Jul-18-2025	0.19 $*	0.79 $*
Jun-18-2025	0.5 $*	0.66 $*
May-18-2025	0.99 $*	0.2 $*
Apr-18-2025	0.76 $*	0.26 $*
Mar-18-2025	0.48 $*	0.44 $*
Feb-18-2025	0.80 $*	0.52 $*
Jan-18-2025	0.50 $*	0.80 $*

Характеристики

Product Description

Multi media industrial water filter/Quartz sand/activated carbon filters for water treatment plant

Used for quartz sand filters, activated carbon filters, softening filters, manganese sand filters, fluoride removal filter.

Sand Filter for Irrigation and Cleaning Water.

Complete Filtration System for Channels - Rivers- Lake and Wells.

Manual control and Flush System. Easy to operate and Durable.

Possible to start from 2 inch - 10 inch

Flow rates : 25m3/h - 900m3/h

Metal and complete system with Sand + Couplings + Disc Filter together. All necessary parts are supplied with the project.

Automatic back flush industrial sand filter is usually called depth filters, water flows through a certain thickness, media layer with a certain particles size, then reached the filtering effect .

The media may be quartz sand ,gravel or granular materials. filtration level depends on the particles diameter and flow speed through filter bed.Nanjing beite provides a series of various forms of such product sand accessories,can also provide control system for using single or multiple parallel situation.

Technical Parameters

Rate of filtration:7~10m/h

Inlet NTU:≤15mg/L

Out NTU:≤5mg/L

Working temperature:normal temperature

Working pressure≤0.4Mpa

Height of filter media:1000~1200mm

Air flow F.A.D for backwashing:18~25L/ m2.S

Aircompressor.Max. Pressure:1~2kg/cm2

Backwash compressed air flow:15L/ m2.S(single floor),12L/ m2.S(double floor) Time of backwashing:5~10 minutes

Multimedia sand-carbon filter-sheet

Drinking Water Mechanical Sand And Carbon Filter Treatment Plant Drinking Water Mechanical Sand And Carbon Filter Treatment

working principle

Multi-media filter makes use of one or several filter material with a certain thickness of a granular or non-granular layer,under a certain pressure to remove suspended impurities in the high turbidity feeding water to purify the water ,The commonly used filter materials consists of quartz sand, actived carbon,anthracite and manganese sand, etc. This multimedia filter is widely used in water treatment turbidity removal,water softening and pretreatment section of pure water treatment,water output turbidity can be below 3NTU.besides,it is applied in pretreatment section for reverse osmosis, electrodialysis, ion exchange as well as softening and demineralization system,also applied in coarse filtration of ordinary water quality for industrial water supply,circulating cooling water, sewage treatment and water recycling.
