Трубы и бар двойная головка/Одна Головка фаски машина цена по прейскуранту

Трубы и бар двойная головка/Одна Головка фаски машина цена по прейскуранту

Категория: >>>
Поставщик: Zhangjiagang,City,Universal,Machinery,Manufacturer,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.52 $*	0.4 $*
Aug-16-2025	0.99 $*	0.57 $*
Jul-16-2025	0.31 $*	0.1 $*
Jun-16-2025	0.37 $*	0.75 $*
May-16-2025	0.94 $*	0.11 $*
Apr-16-2025	0.18 $*	0.29 $*
Mar-16-2025	0.15 $*	0.15 $*
Feb-16-2025	0.50 $*	0.15 $*
Jan-16-2025	0.80 $*	0.32 $*

Характеристики

Technical Parameter

Type	UM52	UM80	UM110	UM150
Max. O.D. Tube	φ15~φ52	φ32~φ80	φ50~φ110	φ60~φ150
Max. O.D. Rod	φ5~φ15	φ9~φ50	φ9~φ50	φ20~φ80
Standard Parts	Knife and Clamp Kit	Knife and Clamp Kit	Knife and Clamp Kit	Knife and Clamp Kit
Optional	Knife and Clamp Kit(Special)	Knife and Clamp Kit(Special)	Knife and Clamp Kit(Special)	Knife and Clamp Kit(Special)
Working Speed	3s	4s	4s	8s
Motor Power	1.5 KW	3 KW	3 KW	4 KW
Spindle Speed	1100RPM	720/900RPM	720/900RPM	450/720RPM
Air Pressure	6~8 kg/cm²(120ML/MIN)	6~8 kg/cm²(120ML/MIN)	6~8 kg/cm²(120ML/MIN)	--
Hydraulic Power	--	--	--	1.5 KW
Hydraulic Pressure	--	--	--	40~70 KG
Size(mm)	650x750x1000	750x900x1050	800x950x1100	1300x1150x1500
Weight	150 KG	270 KG	300 KG	1200 KG

PS: O.D.: Outside Diameter.

The Knife and Clamping Device(Kit) can made to order according to the Customer's requirement.

Pipe & Bar Double Head/Single Head Chamfering Machine factory price

Feature

1: Semi-automatic metal chamfering machine with adjustable Knife;
2: Feeding tube by manual, blade forward and back automatically, due to the high speed, the production capacity increase double more;
3: This machine is good at chamfering inner and out angle of pipe or rod, chamfering and debarring can be finished at one time in fast speed and accuracy;
4: Clamping device and knife holder are designed precision and accurately, which ensure the center line of workpiece and knife holder keep at the same level;
5: Knife holder as designed specially and the blade is normalizing which enable adjusting knife simply.

Pipe & Bar Double Head/Single Head Chamfering Machine factory price

Working Shop

Pipe & Bar Double Head/Single Head Chamfering Machine factory price

Customer Visiting

DH2 DH8

Pipe & Bar Double Head/Single Head Chamfering Machine factory price

Package

package

Pipe & Bar Double Head/Single Head Chamfering Machine factory price

Loading

Loading Pipe & Bar Double Head/Single Head Chamfering Machine factory price

Our Service

1. Reply your inquiry within 12 working hours.
2. Experienced engineer instruct and sales communicate with you in fluent English.
3. According to work pieces specifications, heating requirements, propose best solutions,also reference your ideas.
4. Machine details and working video link for your reference
5. Competitive price with high quality,compare with the same industry.
6. Production: strict quality standard, to produce machine and induction coils.
7. Debugging machine and only good machine will be sent.
8. Tracking goods shipping and provide bill of lading,invoice,packing list and other documents what you need

9. Provide install and technology instruction by sending drawings, email, or telephone,video.
10. If you need, will arrange one engineer to your place, instruct install machine and training operators.
11.Excess warranty period (12 months warranty), you can buy the spare parts from us with special discount price.
12.Provide long-terms technical support, supply whole life after sell service.
